Egenskaper

● Intuitive LCD interface - provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys
● High frequency design - reduces or eliminates bulky transformers resulting in lighter units for ease of handling
● Auto recognition of external batteries - UPS recognizes when external battery packs are attached and automatically adjusts runtime
● Predictive replace battery date - dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning
● Green mode - excellent operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection
● Energy meter - provides actual kilowatt hours of usage for energy conscious users
● Pure sine wave output on battery - simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics
● Single switched outlet group - single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding
● High online efficiency - reduces utility costs, generates less heat
● EPO - attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation
● SmartSlot - customize UPS capabilities with management cards
● Cold-start capable - provides temporary battery power when the utility power is out
● Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
● Scalable runtime - allows additional run time to be quickly added as needed
● Rack/tower convertible - protects the initial investment in the UPS when migrating from tower to rack-mount environment
● Plug-and-Play external batteries - ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS
● Intelligent battery management - maximizes battery performance, life, and reliability through intelligent, precision charging
● Power conditioning - protects connected loads from surges, spikes, lightning, and other power disturbances
● Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
● Automatic restart of loads after UPS shutdown - automatically starts up the connected equipment upon the return of utility power
● Disconnected battery notification - warns when a battery is not available to provide backup power
● Network manageable - provides remote power management of the UPS over the network
● Audible alarms - actively let you know if the unit is on battery, if the battery is low or if there is an overload condition
● LED status indicators - quickly understand unit and power status with visual indicators
● Serial connectivity - provides management of the UPS via a serial port
● USB connectivity - provides management of the UPS via a USB port
● Disconnected battery notification - warns when a battery is not available to provide backup power
● Hot-swappable batteries - ensures clean, uninterrupted power to protected equipment while batteries are being replaced
● Predictive failure notification - provides early-warning fault analysis ensuring proactive component replacement
● Resettable circuit breakers - enables a quick recovery from overload events
● Battery failure notification - provides early-warning fault analysis on batteries enabling timely preventive maintenance
● Adjustable voltage-transfer points - maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation
● Adjustable voltage sensitivity - provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications
● Safety-agency approved - ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment



Teknisk specifikation

Typ av enhet	UPS - rackmonterbar/extern
Höjd (U-format)	2U
Färg	Svart

UPS-teknik	Interaktiv
Inspänning	AC 230 V
Inspänningens område	AC 160 - 286 V
Tillhandahållen frekvens	47 - 63 Hz
Erforderlig frekvens	50/60 Hz ± 3Hz
Inmatningsanslutningar	Ström IEC 60320 C14
Kontaktdetaljer för uteffekt	8 x power IEC 60320 C13
Utspänning	AC 230 V 47 - 63 Hz
Effektkapacitet	600 Watt / 750 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja

Teknik	Bly-syra
Runtime (upp till)	14.2 min vid full laddning 37 min vid halv maskin
Laddningstid	3 timmar
Egenskaper	Underhållsfri, läcksäker

Gränssnitt för fjärradministration	RS-232, USB

Gränssnitt	1 x USB 1 x RS-232 - RJ-45 1 x EPO (emergency power off)
Expansionskortplatser	1 (totalt)/ 0 (ledig) x SmartSlot

Standarder som följs	VDE, EN 62040-2, EAC, RCM, EN 62040-1

Medföljande programvara	APC PowerChute Business Edition

Service och support	Begränsad garanti - 3 år Begränsad garanti - batterier - 2 år

Bredd	43.2 cm
Djup	49.3 cm
Höjd	8.9 cm
Vikt	23 kg
