Egenskaper
Seamless large screens with ultra- narrow bezelThe ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.
Image gap reductionThe VL5G-M series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
Higher viewing angleLarge screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5G-M series is high enough to display vivid colors throughout the screen with no distortion.
Wide viewing angleIt is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5G-M series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.
Easy color adjustmentDepending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
White balance adjustmentIn conventional video walls, white balance was adjustable only in "full-white" mode, but the VL5G-M series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
User-friendly menu structureThe menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.
Intuitive GUIThe GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a large font for better visibility, which is necessary when users want to control displays from relatively far distances.
Teknisk specifikation
Allmänt
Typ av produkt | LED-bakgrundsbelyst, platt LCD-skärm |
Strömförbrukning (max) | 120 Watt |
Energiförbrukning vid drift | 100 Watt |
Diagonalklass | 49" |
Kommersiell användning | Ja - digital skyltning |
Serie | VL5G-M Series |
TV-tuner | Ingen mottagare |
TV-mottagaravkänning | Nej |
Videogränssnitt | HDMI |
HDMI-portskvantitet | 2 portar |
PC-gränssnitt | DVI, DisplayPort |
Lägen | Stående läge, liggande läge |
Bildförbättringar | Image Gap Reduction, Bred synvinkel |
Design | Ultrasmal kant |
Dimensioner | Utan ställ |
Bredd | 107.76 cm |
Djup | 8.97 cm |
Höjd | 60.78 cm |
Vikt | 16.9 kg |
Färg | Svart |
Display
LCD-skärmteknik | IPS |
Upplösning | 1920 x 1080 |
Visningsformat | 1080p |
Bildkvot | 16:9 |
LCD-teknik för bakgrundsbelysning | LED-bakgrundsbelysning |
Bildkontrastförhållande | 1000:1 |
Ljusstyrka | 500 cd/m² |
Bildvinkel | 178 grader |
Bildvinkel (vertikal) | 178 grader |
Svarstid | 8 ms |
Kommersiella funktioner | LG SuperSign Media Editor, kompatibel med SuperSign CMS, SuperSign Control+ kompatibel, SuperSign Control compatible, kompatibel med SuperSign WB |
Driftstimmar / dagar | 24 / 7 |
Egenskaper | Justerbar vitbalans |
Ställ och hållare
Monteringsgränssnitt för platt bildskärm | 600 x 400 mm |
Överensstämmer med VESA | Ja |
Mediespelare
USB-port | Ja |
Antal USB-portar | 1 |
Fjärrkontroll
Typ | Fjärrkontroll |
Batteri ingår | Ja |
Antal batterier som medföljer | 2 |
Nätverks- och Internet-multimedia
Anknytningsbarhet | LAN |
Anslutningar
Anslutningstyp | 2 x HDMI-ingång DisplayPort-inmatning DVI-D-ingång Linjeingång för ljud USB 2.0 DisplayPort-utmatning Linjeutgång för ljud RS-232C in-/utgång Fjärrkontroll Infrared (IrDA) |
Diverse
Inkluderade tillbehör | IR-mottagare, guidefäste |
Medföljande kablar | RS-232C-kabel DisplayPort-kabel |
Standarder som följs | FCC klass A-certifierad, CB, EMC, KC, ERP, NRTL |
Miljöstandarder
ENERGY STAR-certifierad | Ja |
Strömtillförsel
Nätdel | Nätaggregat |
Inspänning | AC 100-240 V (50/60 Hz) |
Mått och vikt (brutto)
Bredd (brutto) | 121.4 cm |
Djup (brutto) | 26.3 cm |
Höjd (brutto) | 77.8 cm |
Vikt (brutto) | 29.3 kg |
Miljöparametrar
Min temperatur vid drift | 0 °C |
Max temperatur vid drift | 40 °C |
Luftfuktighet vid drift | 10 - 80% |
