Produktbeskrivning

WD's exclusive NASware technology, built into every WD Red hard drive, improves NAS storage performance by reducing common hard drive concerns in NAS systems including concerns for things like compatibility, integration, upgradeability, reliability and cost of ownership that are experienced with a hard drive designed for desktop computers.



Egenskaper

Beyond desktop with NASware
WD Red drives include WD's exclusive NASware technology that addresses many of the challenges a traditional desktop hard drive has in a NAS system. WD works directly with the partners to test compatibility and reduce thecustomer's guess work as to which drive is right for their NAS system. Designed to deliver a better customer experience in small NAS systems, this innovative firmware finely balances the most important attributes of performance, power, and reliability in multiple drive environments. The unique algorithms in NASware optimize power and performance without compromising on the attributes that NAS-system owner's value.

Important features for system integrators
In addition to features that make WD Red drives perfect for populating or upgrading NAS systems, NASware brings features that system integrators need when building specialized NAS systems.

Save power and money
NASware optimizes power use resulting in significant power savings and lower hard drive operating temperatures. This improves the overall reliability and performance of the drive and reduces the NAS cost of ownership.

Intelligent error recovery
With built in intelligent error recovery controls, NASware also prevents hard drives from being dropped off the RAID due to extended error recovery. This provides more availability and less down time rebuilding the RAID.

Command completion
To further improve reliability, NASware minimizes the data corruption or loss in the event of an unexpected power loss by completing the command in process before shutting down.



Teknisk specifikation

Typ av enhet	Hårddisk - inbyggd
Kapacitet	2 TB
Formfaktor	3.5"
Gränssnitt	SATA 6Gb/s
Buffertstorlek	64 MB
Egenskaper	NAS-kompatibel, NASware-teknik, 3D Active Balance Plus, 24x7 kontinuerlig drift, Felavhjälpningskontroll, CMR (Conventional Magnetic Recording), RAID-optimerade NAS-systems
Bredd	10.16 cm
Djup	14.7 cm
Höjd	2.61 cm
Vikt	570 g

Hårddiskens överföringshastighet	600 MBps (extern)
Intern datafrekvens	215 MBps
Spindelhastighet	5400 rpm

MTBF (genomsnittstid mellan fel)	1,000,000 timmar
Dygnet-runt drift	Ja
Oåterkalleligt fel	1 per 10^14
Ladda/ladda ur cykler	600,000

Gränssnitt	1 x SATA 6 Gb/s
Kompatibelt fack	3.5"

Strömkonsumtion	4.8 Watt (läsning/skrivning) 3.1 Watt (inaktiv) 0.4 Watt (viloläge) 0.4 Watt (viloläge)

Standarder som följs	UL, TUV, VCCI, BSMI, FCC, RoHS, KC, RCM, UKCA, CB Scheme, ICES 003, Maghreb, NMB-003

Service och support	Begränsad garanti - 3 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	65 °C
Min temperatur vid förvaring	-40 °C
Max temperatur vid förvaring	70 °C
Stöttolerans (vid drift)	70 g @ 2 ms
Stöttolerans (i vila)	300 g @ 2 ms
