Produktbeskrivning
Ideal for high-performing modern enterprise network cores, with stacking to create a resilient local or distributed solution, and integrated management of wired and wireless network devices. These powerful switches have 100 Gigabit connectivity built-in, and are expandable, delivering the capacity to enable today’s Smart City and IoT networks.
Viktiga egenskaper
Allied Telesis x950-52XTQm. Switch type: Managed, Switch layer: L3+. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 96000 entries, Switching capacity: 1920 Gbit/s. Networking standards: IEEE 802.1AE, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1v, IEEE.... Rack mounting, Form factor: 1U
Teknisk specifikation
Management features
| Switch type | Managed |
|---|
| Switch layer | L3+ |
|---|
| Quality of Service (QoS) support | Yes |
|---|
| Web-based management | Yes |
|---|
| Traffic classification | Yes |
|---|
| ARP inspection | Yes |
|---|
| Traffic shaping | Yes |
|---|
| System event log | Yes |
|---|
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 48 |
|---|
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
|---|
Network
| Networking standards | IEEE 802.1AE,IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ad,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.2ad,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3u |
|---|
| 10G support | Yes |
|---|
| Port mirroring | Yes |
|---|
| Full duplex | Yes |
|---|
| Flow control support | Yes |
|---|
| Broadcast storm control | Yes |
|---|
| Link aggregation | Yes |
|---|
| VLAN support | Yes |
|---|
| Virtual LAN features | Policy-based VLAN,Stacked VLAN |
|---|
| Number of VLANs | 4000 |
|---|
Data transmission
| MAC address table | 96000 entries |
|---|
| Switching capacity | 1920 Gbit/s |
|---|
| Forwarding rate | 1309 Mpps |
|---|
| Static route | Yes |
|---|
| Jumbo frames support | Yes |
|---|
| Jumbo frames | 10000 |
|---|
| Packet buffer memory | 16 MB |
|---|
Security
| DHCP features | DHCPv6 client,DHCPv6 relay,DHCPv6 snooping |
|---|
| Access Control List (ACL) | Yes |
|---|
| IGMP snooping | Yes |
|---|
| SSH/SSL support | Yes |
|---|
| MAC address filtering | Yes |
|---|
| BPDU filtering/protection | Yes |
|---|
| Loop protection | Yes |
|---|
| Security algorithms | EAP,HTTPS,MD5,PEAP,SSH,SSH-2,SSL/TLS,TLS,TTLS |
|---|
Multicast features
| Multicast support | Yes |
|---|
| Multicast MAC address table | 8000 entries |
|---|
Design
| Rack mounting | Yes |
|---|
| Stackable | Yes |
|---|
| Form factor | 1U |
|---|
| Product colour | Grey |
|---|
Power
| Power source | AC/DC |
|---|
| Power supply included | Yes |
|---|
| Number of power supply units | 2 |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 47/63 Hz |
|---|
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | No |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
|---|
| Storage temperature (T-T) | -25 - 70 °C |
|---|
| Operating relative humidity (H-H) | 5 - 90 % |
|---|
| Storage relative humidity (H-H) | 5 - 95 % |
|---|
| Operating altitude | 0 - 3050 m |
|---|
Weight & dimensions
| Width | 441 mm |
|---|
| Depth | 449 mm |
|---|
| Height | 44 mm |
|---|
