Produktbeskrivning

The Allied Telesis GS910 Series offers unmanaged Gigabit switching solutions for the desktop, and small networks. The series has internal and external power supply versions, and also features network loop guard technology, which automatically detects any unexpected network loops, and prevents network devices from broadcast packet storms.

Overview
With minimal to no set-up, GS910 Series switches provide simple and seamless connectivity to existing network infrastructure. Each unmanaged switch is backed with a lifetime limited warranty.

High performance
The GS910 Series delivers the high speed and high performance demanded by today’s high-bandwidth applications, such as video, graphics and industrial design.

Quality and reliability
Allied Telesis is a world-wide leader in unmanaged Ethernet switches. Shipping more than 250,000 unmanaged switches every year, Allied Telesis offers proven reliability, and industry-recognized quality.

Loop detection
GS910 Series switches provide network loop detection by using Loop Detection Frame (LDF). LDF detects network loops, and shuts down ports where the loop is detected. After the loop is solved, the port that has shut down is automatically recovered.

Environmentally-friendly eco-switch
Allied Telesis GS910 Series ecofriendly switches conform with the Allied Telesis commitment to environmentally-friendly
processes and products. They are designed to minimize power consumption through the use of a high-efficiency power supply and a low-power chipset. With low power consumption and a reduction in power outside regular work hours (overnight mode), as well as other power-saving features included as standard, the Allied Telesis GS910 Series truly lives
up to its eco-friendly reputation. Not only does this help the planet by reducing the carbon footprint of each switch, it also lowers the Total Cost of Ownership (TCO) to the user, as the device costs less to run, and features improved reliability.



Viktiga egenskaper

Allied Telesis AT-GS910/16. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Wall mountable



Teknisk specifikation

Switch type	Unmanaged

Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Compatible memory cards	Not supported

Networking standards	IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x
10G support	No
Copper ethernet cabling technology	10BASE-T,100BASE-T,1000BASE-T
Full duplex	Yes
IP routing	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Flow control support	Yes

MAC address table	8000 entries
Switching capacity	32 Gbit/s
Throughput	23.8 Mpps
Jumbo frames support	Yes
Jumbo frames	10000
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (100 Mbps)	148800 pps

DHCP features	DHCP client
BPDU filtering/protection	Yes
SSH/SSL support	Yes
Loop protection	Yes

Product colour	Grey
Housing material	Metal
Wall mountable	Yes
Safety	UL60950-1, 2nd Edition CSA C22.2 No.60950-1-07, 2nd Edition IEC60950-1(UL-EU, UL-CB)
Certification	EAC certification EN55024 ICES Class A VCCI Class A FCC Class A RCM CE EN55022 CISPR 55022 RoHS

Buffer size	524 KB

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Output current	0.3 A
Power consumption (max)	12 W
Power plug type	Type C

Power over Ethernet (PoE)	No

Operating temperature (T-T)	0 - 50 °C

Width	263 mm
Depth	179 mm
Height	380 mm
Weight	1500 g

Quick start guide	Yes
User guide	Yes
Mounting brackets included	Yes

Harmonized System (HS) code	85176990
