Security through emergency power
An APC Easy-UPS has a built-in battery that ensures that all connected devices, such as a NAS, router, modem and media box, continue to work if the power goes out. This prevents downtime, damage to equipment, and loss of data.

Safety and convenience
In addition, this safe APC UPS protects valuable equipment against peak voltage caused, for example, by lightning strikes. Because the APC Easy-UPS BV500I-GR can also be mounted on the wall and is equipped with 4 rotated sockets (45°), this APC emergency power supply is also a suitable UPS for the meter cupboard.

Expected battery life
Load in Watts, battery life in Minutes:
10W = 100 Min.
40W = 40 Min.
80W = 18 Min.
120W = 5 Min.
180W = 3 Min.
240W = 0.5 Min.

Extends battery life
The AVR function extends both the expected battery life and the expected runtime by correcting both low and high voltages without discharging the battery.

Warranty extension
The factory warranty of the BV500I-GR is 2 years and you can upgrade to 5 years with the APC service pack (WBEXTWAR3YR-SP-01A).



Viktiga egenskaper

APC Easy-UPS BV500I-GR - 4x Schuko socket, 500VA. UPS topology: Line-Interactive, Output power capacity: 0.5 kVA, Output power: 300 W. AC outlet types: Type F, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 4.5 Ah, Battery voltage: 12 V. Form factor: Compact, Product colour: Black, Cable length: 1.52 m. Compliance certificates: RoHS, Certification: CE REACH



Teknisk specifikation

UPS topology	Line-Interactive
Output power capacity	0.5 kVA
Output power	300 W
Waveform	Sine
Input operation voltage (min)	170 V
Input operation voltage (max)	280 V
Input frequency	50/60 Hz
Output frequency	50/60 Hz
Automatic Voltage Regulation (AVR)	Yes
Transfer time (Line Mode to Battery Mode)	6 ms
Surge energy rating	156 J
Number of input phases	1
Number of output phases	1
Noise level	40 dB
Surge protection	Yes
Audible alarm(s)	Yes
Audible alarm modes	Alarm when on battery,Low battery alarm,Overload alarm

AC outlet types	Type F
AC outlets quantity	4 AC outlet(s)
SmartSlot	No
SmartConnect port	No

Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	4.5 Ah
Battery voltage	12 V
Battery recharge time	8 h
Cold start	Yes

Form factor	Compact
Product colour	Black
Cable length	1.52 m
LED indicators	Yes
Certification	CE REACH

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Operating altitude	0 - 1968.3 m

Compliance certificates	RoHS

Width	160 mm
Depth	305 mm
Height	92 mm
Weight	3900 g
Package width	373 mm
Package depth	143 mm
Package height	237 mm
Package weight	4200 g

Management card included	No

Harmonized System (HS) code	85078000

Nominal output voltage	230 V
