Produktbeskrivning

At 1980W/2200VA this Smart-UPS On-Line Lithium-Ion battery backup system provides high-density, double conversion on-line pure sine wave power, preinstalled Netwrok Management Card. In addition to cleaner, quieter power protection, this UPS is only around half size and weight of comparable UPS systems with similar runtime and has flexible rack and tower installation options. A new extended runtime battery pack provides longer runtime in a small 2U footprint while tripling the life expectancy of the UPS. SRTL 1-3kVA UPSs with this rong runtime battery pack is perfect for applications critical for runtime.



Viktiga egenskaper

APC Smart-UPS On-Line, 2200VA, Lithium-ion, Rackmount 4U, 230V, 6x C13+2x C19 IEC outlets, Network Card, Extended long runtime, Rail kit included. UPS topology: Double-conversion (Online), Output power capacity: 2.2 kVA, Output power: 1980 W. AC outlet types: C13 coupler, C19 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Lithium-Ion (Li-Ion), Battery voltage: 48 V, Battery life (max): 10 year(s). Form factor: Rackmount/Tower, Product colour: Black, Silver, Rack capacity: 4U. Sustainability certificates: Green Premium



Teknisk specifikation

UPS topology	Double-conversion (Online)
Output power capacity	2.2 kVA
Output power	1980 W
Waveform	Sine
Input operation voltage (max)	230 V
Input frequency	40 - 70 Hz
Output frequency	50/60 Hz
Surge energy rating	432 J
Crest factor	3:1
Output voltage Total Harmonic Distortion (THD)	2 %
Audible alarm(s)	Yes

AC outlet types	C13 coupler,C19 coupler
AC outlets quantity	8 AC outlet(s)
SmartSlot	Yes
SmartConnect port	No

Battery technology	Lithium-Ion (Li-Ion)
Battery voltage	48 V
Battery life (max)	10 year(s)

Form factor	Rackmount/Tower
Product colour	Black,Silver
Rack capacity	4U
Cable length	1.83 m
International Protection (IP) code	IP20

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
Operating altitude	0 - 3048 m

Sustainability certificates	Green Premium

Width	432 mm
Depth	639 mm
Height	171 mm
Weight	44500 g

Rack mount kit	Yes
Management card included	Yes
