Produktbeskrivning

Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance. Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.

Cold-start capable provides temporary battery power when the utility power is out. Hot-swappable batteries ensure clean, uninterrupted power to protected equipment while batteries are being replaced. Dataline surge protection provides protection of connected equipment from power surges on the data lines.



Egenskaper

Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Audible alarms
Provide notification of changing flywheel conditions.

Battery failure notification
It provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Power-saving outlets
Automatically cuts power to idle equipment to conserve electricity.

Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.

Cold-start capable
It provides temporary battery power when the utility power is out.

Hot-swappable batteries
It ensures clean, uninterrupted power to protected equipment while batteries are being replaced.

Dataline surge protection
It provides protection of connected equipment from power surges on the data lines.

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Adjustable voltage-transfer points
It maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.

User-replaceable batteries
It increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).

Boost and trim Automatic Voltage Regulation (AVR)
It gives higher application availability by correcting low and high voltage conditions without using the battery.

Intelligent battery management
It maximizes battery performance, life, and reliability through intelligent, precision charging.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.



Teknisk specifikation

Typ av enhet	UPS - extern
Batterityp	Intern
Lokalisering	Belgien, Frankrike

UPS-teknik	Interaktiv
Inspänning	AC 230 V
Erforderlig frekvens	47 - 63 Hz
Utspänning	AC 230 V
Effektkapacitet	720 Watt / 1200 VA
Överspänningsskydd	Nätverk - RJ-45 Telefonlinje - RJ-11
Utvågform	Stegapproximation till en sinusvåg
Spänningsavledning	Ja
Energivärdering	445 joule
Kretsskydd	Strömbrytare

Antal	1
Teknik	Bly-syra
Runtime (upp till)	7.6 min vid full laddning 19.9 min vid halv maskin
Laddningstid	8 timmar

Gränssnitt för fjärradministration	USB

Gränssnitt	1 x hantering (USB)

Medföljande kablar	USB-kabel - extern Strömkabel - integrerad - 1.8 m
Egenskaper	Hotswap-batteri, Lysdiodindikator, Hörbart larm, LCD-bildskärm, Automatisk spänningsreglering (AVR), kallstartfunktion
Standarder som följs	UL 1449, RoHS, REACH

Service och support	Begränsad garanti - 2 år Europeiska Unionen: begränsad garanti - 3 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	45 dBA

Bredd	11.2 cm
Djup	38 cm
Höjd	30.1 cm
Vikt	11.6 kg

Emballagets bredd	23.8 cm
Emballagets djup	48.8 cm
Emballagets höjd	38.7 cm
Emballagets vikt	13.2 kg
