Produktbeskrivning
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance. Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.
Cold-start capable provides temporary battery power when the utility power is out. Hot-swappable batteries ensure clean, uninterrupted power to protected equipment while batteries are being replaced. Dataline surge protection provides protection of connected equipment from power surges on the data lines.
Egenskaper
Green modePatent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Audible alarmsProvide notification of changing flywheel conditions.
Battery failure notificationIt provides early-warning fault analysis on batteries enabling timely preventive maintenance.
Power-saving outletsAutomatically cuts power to idle equipment to conserve electricity.
Battery-protected and surge-only outletsReserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.
Cold-start capableIt provides temporary battery power when the utility power is out.
Hot-swappable batteriesIt ensures clean, uninterrupted power to protected equipment while batteries are being replaced.
Dataline surge protectionIt provides protection of connected equipment from power surges on the data lines.
Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.
Adjustable voltage-transfer pointsIt maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
User-replaceable batteriesIt increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).
Boost and trim Automatic Voltage Regulation (AVR)It gives higher application availability by correcting low and high voltage conditions without using the battery.
Intelligent battery managementIt maximizes battery performance, life, and reliability through intelligent, precision charging.
Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Teknisk specifikation
Allmänt
Typ av enhet | UPS - extern |
Batterityp | Intern |
Nätdel
Inspänning | AC 230 V |
Inspänningens område | AC 160 - 286 V |
Tillhandahållen frekvens | 50/60 Hz |
Erforderlig frekvens | 50/60 Hz |
Inmatningsanslutningar | 1 x power CEE 7/7 |
Kontaktdetaljer för uteffekt | 3 x power CEE 7/7 (UPS och spänningsutjämnare) 3 x power CEE 7/7 (spänningsutjämnare) |
Utspänning | AC 230 V 50/60 Hz |
Effektkapacitet | 720 Watt / 1200 VA |
Överspänningsskydd | Nätverk - RJ-45 Telefonlinje - RJ-11 |
Utvågform | Stegapproximation till en sinusvåg |
Spänningsavledning | Ja |
Energivärdering | 420 joule |
Kretsskydd | Strömbrytare |
Batteri
Antal | 1 |
Teknik | Bly-syra |
Runtime (upp till) | 5 min vid full laddning 18 min vid halv maskin |
Laddningstid | 8 timmar |
Nätverk
Gränssnitt för fjärradministration | USB |
Expansion/Anslutning
Gränssnitt | 1 x hantering (USB) |
Diverse
Medföljande kablar | USB-kabel - extern Strömkabel - integrerad - 1.8 m |
Egenskaper | Hörbart larm, LCD-bildskärm, Automatisk spänningsreglering (AVR), kallstartfunktion |
Standarder som följs | NEMKO, RoHS, REACH |
Programvara / Systemkrav
Medföljande programvara | APC PowerChute Personal Edition |
Tillverkarens garanti
Service och support | Begränsad garanti - ersättningsprodukt eller reparation - 2 år Europeiska Unionen: begränsad garanti - ersättningsprodukt eller reparation - 3 år |
Miljöparametrar
Min temperatur vid drift | 0 °C |
Max temperatur vid drift | 40 °C |
Luftfuktighet vid drift | 0 - 95% |
Ljudnivå | 45 dBA |
Mått och vikt
Bredd | 11.2 cm |
Djup | 38 cm |
Höjd | 30.1 cm |
Vikt | 13 kg |
Mått och vikt (brutto)
Emballagets bredd | 23.5 cm |
Emballagets djup | 49 cm |
Emballagets höjd | 39 cm |
Emballagets vikt | 13.8 kg |
