Produktbeskrivning
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. Allow flexibility for setup in tight locations and mounting on wall or other surfaces. Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Egenskaper
Automatic Voltage Regulation (AVR)Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
Wall-mount holesAllow flexibility for setup in tight locations and mounting on wall or other surfaces.
Advanced Safety FeaturesSafeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Battery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenance.
Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.
Audible alarmsProvides notification of changing utility power and UPS power conditions
LED IndicatorsProvide easy-to-read status of the unit and utility power conditions.
Battery backup and surge protectionOutlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
Battery and surge protected outletsBack up and protect your hardware and data during power outages, surges and spikes.
Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Boost Automatic Voltage Regulation (AVR)Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Cold-start capableProvides temporary battery power when the utility power is out.
Transformer-block spaced outletsProtect equipment with input transformer blocks without blocking access to other receptacles.
Sleek designSlim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
Teknisk specifikation
Allmänt
Typ av enhet | UPS - extern |
Nätdel
UPS-teknik | Interaktiv |
Inspänning | AC 230 V |
Inspänningens område | AC 170 - 280 V |
Tillhandahållen frekvens | 50/60 Hz ± 1% |
Erforderlig frekvens | 50 - 60 Hz ± 5% |
Inmatningsanslutningar | 1 x power CEE 7/7 |
Kontaktdetaljer för uteffekt | 4 x power CEE 7/3 (UPS och spänningsutjämnare) - 230 V |
Utspänning | AC 230 V ± 10% - 50/60 Hz |
Effektkapacitet | 600 Watt / 1000 VA |
Utvågform | Stegapproximation till en sinusvåg |
Spänningsavledning | Ja |
Kretsskydd | Strömbrytare |
Batteri
Teknik | Bly-syra |
Tillförd spänning | 12 V |
Kapacitet | 9 Ah |
Laddningstid | 6 timmar |
Transfertid | 6 ms |
Egenskaper | Underhållsfri, förseglad, spillsäker |
Diverse
Medföljande kablar | Strömkabel - extern - 1.52 m |
Egenskaper | Monterbar på vägg, Hörbart larm, LED-fönster, överhettningsskydd, Automatisk spänningsreglering (AVR), överspänningsskydd, överbelastningsskydd, underspänningsskydd, automatiskt självtest, intelligent batterihantering |
Standarder som följs | RoHS, REACH, SVHC |
Tillverkarens garanti
Service och support | Begränsad garanti - 2 år |
Miljöparametrar
Min temperatur vid drift | 0 °C |
Max temperatur vid drift | 40 °C |
Luftfuktighet vid drift | 0 - 90% |
Ljudnivå | 40 dBA |
Mått och vikt
Bredd | 16.05 cm |
Djup | 30.5 cm |
Höjd | 9.25 cm |
Vikt | 5.7 kg |
Mått och vikt (brutto)
Emballagets bredd | 14.3 cm |
Emballagets djup | 37.3 cm |
Emballagets höjd | 23.7 cm |
Emballagets vikt | 6 kg |
