Produktbeskrivning

The user-replaceable batteries increase availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR). It ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.



Egenskaper

Multiple mounting methods
It allows for standardization on one product for use in different environments.

Plug-and-Play external batteries
It ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Cold-start capable
It provides temporary battery power when the utility power is out.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Wide input voltage range
It is designed for harsh electrical environments to save battery life.

Intelligent battery management
It maximizes battery performance, life, and reliability through intelligent, precision charging.

LED indicators
Provide easy-to-read status of the unit and utility power conditions.

Hot-swappable batteries
It ensures clean, uninterrupted power to protected equipment while batteries are being replaced.

User-replaceable batteries
It increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).



Teknisk specifikation

Typ av enhet	UPS - kan monteras på DIN-skena
Färg	Svart

UPS-teknik	Interaktiv
Inspänning	AC 220/230/240 V
Inspänningens område	AC 160 - 285 V
Inspänningens område (justeringsbart)	AC 151 - 302 V
Erforderlig frekvens	50/60 Hz
Inmatningsanslutningar	1
Kontaktdetaljer för uteffekt	1 x 3-trådig kabel (1PH + N + G)
Utspänning	AC 220/230/240 V ± 5%
Effektkapacitet	325 Watt / 500 VA
Spänningsavledning	Ja
Energivärdering	540 joule
Kretsskydd	Strömbrytare
Effektivitet	94%

Antal	1
Teknik	Bly-syra
Runtime (upp till)	8 min vid full laddning 24 min vid halv maskin
Laddningstid	2.5 timmar

Gränssnitt för fjärradministration	RS-232

Gränssnitt	1 x hantering (RS-232) - 9 pin D-Sub (DB-9)
Expansionskortplatser	1 (totalt)/ 1 (ledig) x SmartSlot

Standarder som följs	UL, UL 1449, RoHS, REACH

Service och support	Begränsad garanti - utbyte - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	55 dBA

Bredd	36.2 cm
Djup	17.1 cm
Höjd	14.8 cm
Vikt	12.86 kg

Emballagets bredd	29.7 cm
Emballagets djup	29.7 cm
Emballagets höjd	48.1 cm
Emballagets vikt	13.32 kg
