Produktbeskrivning
Marine Application Filter features intelligent battery management, which maximizes battery performance, life, and reliability through intelligent, precision charging. Periodic battery self-test ensures early detection of a battery that needs to be replaced. Predicative failure notification provides early-warning fault analysis ensuring proactive component replacement.
Egenskaper
Automatic internal bypassIt supplies utility power to the connected loads in the event of a UPS overload condition or fault.
Scalable runtimeIt allows additional run time to be quickly added as needed.
Intelligent battery managementIt maximizes battery performance, life, and reliability through intelligent, precision charging.
Hot-swappable batteriesThey ensure clean, uninterrupted power to protected equipment while batteries are being replaced.
Automatic restart of loads after UPS shutdownIt automatically starts up the connected equipment upon the return of utility power.
Network manageableIt provides remote management of the UPS over the network.
LED status indicatorsQuickly understand unit and power status with visual indicators.
Plug-and-Play external batteriesThey ensure clean, uninterrupted power to the loads when adding extra runtime to the UPS.
Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.
Predicative failure notificationIt provides early-warning fault analysis ensuring proactive component replacement.
Frequency and voltage regulationIt gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
Power conditioningIt protects connected loads from surges, spikes, lightning, and other power disturbances.
Input power factor correctionIt minimizes installation costs by enabling the use of smaller generators and cabling.
Teknisk specifikation
Allmänt
Typ av enhet | Överspänningsskydd - kan monteras i rack |
Färg | Svart |
Nätdel
Inspänning | AC 208/220/230/240 V |
Inspänningens område | AC 100 - 240 V |
Erforderlig frekvens | 47 - 63 Hz |
Inmatningsanslutningar | 1 x ström IEC 60320 C20 |
Kontaktdetaljer för uteffekt | 1 x ström IEC 60320 C19 |
Utspänning | AC 200/208/220/230/240 V |
Effektkapacitet | 3000 VA |
Diverse
Medföljande kablar | Strömkabel - extern - 2.4 m |
Standarder som följs | RoHS, REACH, DNV |
Tillverkarens garanti
Service och support | Begränsad garanti - material och tillverkning - 2 år Begränsad garanti - utbyte - 2 år |
Miljöparametrar
Min temperatur vid drift | 0 °C |
Max temperatur vid drift | 55 °C |
Luftfuktighet vid drift | 0 - 95% |
Mått och vikt
Bredd | 43.2 cm |
Djup | 27.9 cm |
Höjd | 4.4 cm |
Vikt | 5.1 kg |
Mått och vikt (brutto)
Emballagets bredd | 38.1 cm |
Emballagets djup | 55.9 cm |
Emballagets höjd | 7.6 cm |
Emballagets vikt | 6.4 kg |
Kompatibilitetsinformation
Designat för | P/N: SURT1000XLIM, SURTD2200XLIM, SURTD3000XLIM |
