Produktbeskrivning

The NetShelter SX is a multi-functional rack enclosure influenced by customer feedback from around the world. These enclosures are designed to meet IT market trends and applications ranging from high density computing and networking to broadcast and audio/video. With a strong focus on cooling, power distribution, cable management and environmental monitoring, the NetShelter SX rack enclosure provides a reliable rack-mounting environment for mission-critical equipment.



Egenskaper

Optimized for high-capacity cable management systems
NetShelter SX enclosures are optimized for use with high-capacity cable management systems that attach to equipment mounting rails inside enclosures aligning with equipment mounting U spaces and provide channels for routing and managing cabling.

Cable access openings with pre-installed brushes
Large cable access slots in the roof provides access for overhead cable egress. The bottom design allows for unobstructed cable access through a raised floor. Roof includes openings with brush strips pre-installed in locations biased towards the front of the enclosure to allow for data cable pass through and provisions for air containment.

Quick-release doors
Front door can be moved to the opposite side or interchanged with rear doors. Doors are easily removed with simple lift-off design.

Low-profile casters and adjustable leveling feet
Enclosures are shipped standard with both leveling feet and casters. Leveling feet can be quickly adjusted through the use of a screwdriver or drill, eliminating the need to reach underneath with a wrench.



Teknisk specifikation

Produkttyp	Rack
Produktmaterial	16 gauge stål, 18 gauge stål, 14 gauge stål
Förpackningens innehåll	Stödhjulssats för rack, rackutjämningsfötter, sidopaneler, framlucka, justerbara vertikala monteringsskenor, tak, tangenter, delad perforerad bakdörr, byggnadsmaskinvara, monteringsmaskinvara
Stativstorlek	19"
Höjd (U-format)	42U
Bredd	60 cm
Djup	107 cm
Höjd	199.1 cm
Vikt	125.09 kg
Färg	Svart

Viktgräns	1364 kg
Monteringssats	Inkluderat
Antal hjul	4
Montering erfordras	Ja
Egenskaper	Inställningsbart djup, delad bakdörr, integrerad kabelhantering, ventilationssystem, stötmadrassförpackning, perforerade framdörrar, snabbfrigöringsdörrar, låsbara bakdörrar, välvd, tassar med justerbar höjd, justerbara vertikala monteringsskenor, inbyggd elektrisk jordning
Standarder som följs	EIA-310-E, UL 60950, RoHS, REACH

Service och support	Begränsad garanti: - 5 år
