Egenskaper

● Detect 10/100 Mbps connection speeds
● Provide a data log accessible by File Transfer Protocol (FTP), Secure CoPy (SCP), or a Web browser
● Provide an event log that is accessible by Telnet, Secure SHell (SSH), FTP, SCP, or a Web browser
● Generate system log (Syslog) messages
● Enable you to configure a BOOTstrap Protocol (BOOTP) or Dynamic Host Configuration Protocol (DHCP) server to provide the TCP/IP values a Network Management Card needs for network communication
● Generate e-mail notifications for UPS or system events
● Limit SNMP traps, e-mail notification, and event logging based on severity and categories of events
● Enable you to configure multiple Network Management Cards simultaneously over the network
● Provide enhanced security by supporting SSH, Secure Sockets Layer (SSL) and Secure CoPy (SCP)



Teknisk specifikation

Typ av enhet	Adapter för administration på distans
Formfaktor	Insticksmodul
Gränssnittstyp (buss)	SmartSlot

Portar	10/100 Ethernet
Anslutningsteknik	Kabelansluten
Typ av kablage	Ethernet 10Base-T, Ethernet 100Base-TX
Datalänkprotokoll	Ethernet, Fast Ethernet
Dataöverföringshastighet	100 Mbps
Nätverks/transportprotokoll	TCP/IP
Protokoll för administration på distans	SNMP 1, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2
Funktioner	2 048-bitars kryptering, E-postavisering, stöd för IPv6, fast programvara kan uppdateras, RADIUS-stöd, temperatursensor, IPv4-support

Gränssnitt	1 x 100Base-TX - RJ-45 1 x management (RS-232)

Krypteringsalgoritm	SSL
Standarder som följs	GOST, ICES-003, VCCI klass A ITE, EN55024, EN55022 klass A, AS/NZ 3548 Class A, RoHS, FCC Part 15 A, C-Tick Class A, REACH

Medföljande programvara	Drivrutiner och hjälpprogram

Bredd	12.1 cm
Djup	11.4 cm
Höjd	3.8 cm
Vikt	90 g

Service och support	Begränsad garanti - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	45 °C
Luftfuktighet vid drift	0 - 95%

Designat för

P/N: AP9610, G55TUPM100HMS, G55TUPM100HXS, G55TUPM120HMS, G55TUPM120HXS, G55TUPM20HMS, G55TUPM20HXS, G55TUPM30HMS, G55TUPM30HXS, G55TUPM40HXS, G55TUPM60HMS, G55TUPM80HMS, G55TUPM80HXS, G55TUPU100HMS, G55TUPU100HXS, G55TUPU120HMS, G55TUPU120HXS, G55TUPU20HMS, G55TUPU20HXS, G55TUPU30HMS, G55TUPU30HXS, G55TUPU60HXS, G55TUPU80HMS, G55TUPU80HXS, GVX1000K1000GS, GVX1000K1000HS, GVX1000K1250GS, GVX1000K1250HS, GVX1000K1500GS, GVX1000K1500HS, GVX1000K750GS, GVX1000K750HS, GVX1250K1000GS, GVX1250K1000HS, GVX1250K1250GS, GVX1250K1250HS, GVX1250K1500GS, GVX1500K1250GS, GVX1500K1500GS, GVX1750K1500GS, GVX500K1000GS, GVX500K1000HS, GVX500K1250GS, GVX500K1250HS, GVX500K1500GS, GVX500K1500HS, GVX500K500GS, GVX500K500HS, GVX500K750GS, GVX500K750HS, GVX625K625GS, GVX625K625HS, GVX750K1000GS, GVX750K1000HS, GVX750K1250GS, GVX750K1250HS, GVX750K1500GS, GVX750K1500HS, GVX750K500GS, GVX750K500HS, GVX750K750GS, GVX750K750HS, NBRK0570, NBWL0455A
