Produktbeskrivning

The Network Management Card for Easy UPS 3 Series enables secure remote monitoring and control of one Easy UPS 3S, Easy UPS 3M or Easy UPS 3L through the easy-to-use web browser interface, via EcoStruxure™ IT Software or another SNMP-enabled system. The high-speed processor provides a fast and powerful experience offering gigabit ethernet connectivity and simultaneous multiple user logins. Best-in-class security compliance keeps sensitive data secure.  The Network Management Card includes a 1-year Secure NMC Subscription which provides automatic access to new features, enhancements, and advanced support to ensure the most resilient, secure and sustainable IT infrastructure.



Viktiga egenskaper

APC Network Management Card, Network Management Cards, for Easy UPS 3 Series, 3-Phase, remotely monitor and manage the UPS. Product type: Network management card, Product colour: Black, Metallic, MIB support: PowerNet MIB. Management protocols: BACnet. Interface type: RJ-45, Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Compliance certificates: Federal Communications Commission (FCC), ICES, RoHS, VCCI, Certification: AS/NZS, CISPR 32, EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6,.... Width: 52 mm, Depth: 80 mm, Height: 44 mm



Teknisk specifikation

Product type	Network management card
Product colour	Black,Metallic
MIB support	PowerNet MIB
Easy to use	Yes
Compatibility	Easy UPS 3 Series
Certification	AS/NZS, CISPR 32, EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN/IEC 62040-2, FCC Class A, ICES-003, VCCI class A

Interface type	RJ-45
Ethernet LAN (RJ-45) ports	1

Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000
Security algorithms	HTTPS,SNMP,SNMPv3,SSH

Web-based management	Yes
Management protocols	BACnet
Password protection	Yes
Syslog	Yes
Reset button	Yes

Number of phases	3

Width	52 mm
Depth	80 mm
Height	44 mm
Weight	50 g
Package width	170 mm
Package depth	240 mm
Package height	50 mm
Package weight	300 g

Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-15 - 65 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 15240 m

Cables included	USB
Manual	Yes

Compliance certificates	Federal Communications Commission (FCC),ICES,RoHS,VCCI
Total carbon footprint (kg of CO2e)	69.41
Sustainability compliance	Yes
