Produktbeskrivning

Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (13) C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.



Viktiga egenskaper

APC AP6020A. PDU types: Basic, Rack capacity: 0U/1U, Type: Single-phase. AC outlets quantity: 13 AC outlet(s), AC outlet types: C13 coupler, Power plug: C20 coupler. Nominal input voltage: 100-240 V, Maximum current: 20 A, AC input frequency: 50 - 60 Hz. Compliance certificates: RoHS, Certification: cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH. Width: 44 mm, Depth: 93 mm, Height: 388 mm



Teknisk specifikation

PDU types	Basic
Type	Single-phase
Rack capacity	0U/1U
Mounting	Horizontal/Vertical
Product colour	Black

AC outlets quantity	13 AC outlet(s)
Power plug	C20 coupler
AC outlet types	C13 coupler
Output connections	IEC 320 C13

Certification	cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH

Nominal input voltage	100-240 V
AC input frequency	50 - 60 Hz
Maximum current	20 A
Load capacity	3680 VA
Maximum input current per phase	16 A
Maximum total current draw per phase	16 A
Maximum power	3680 W

Width	44 mm
Depth	93 mm
Height	388 mm
Weight	1500 g

Package weight	2020 g
Package width	210 mm
Package depth	76 mm
Package height	436 mm

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-15 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3048 m

Compliance certificates	RoHS
Total carbon footprint (kg of CO2e)	38.04
