Produktbeskrivning

Intuitive LCD interface provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.

Predictive replace battery date dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.



Egenskaper

Intuitive LCD interface
Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.

Predictive replace battery date
Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.

Energy meter
Provides actual kilowatt hours of usage for energy conscious users.

Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

Single switched outlet group
Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.

High online efficiency
Reduces utility costs, generates less heat.

SmartSlot
Customize UPS capabilities with management cards.

Cold-start capable
Provides temporary battery power when the utility power is out.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.



Teknisk specifikation

Typ av enhet	UPS - kan monteras i rack
Höjd (U-format)	2U
Färg	Svart
Kombinerad med	APC UPS Network Management Card

UPS-teknik	Interaktiv
Inspänning	AC 230 V
Inspänningens område	AC 160 - 286 V
Inspänningens område (justeringsbart)	AC 151 - 302 V
Erforderlig frekvens	50 Hz ± 3Hz
Inmatningsanslutningar	1 x ström IEC 60320 C14
Kontaktdetaljer för uteffekt	Power IEC 60320 C13
Utspänning	AC 230 V ± 5%
Effektkapacitet	1000 Watt / 1500 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja
Energivärdering	459 joule
Kretsskydd	Strömbrytare

Teknik	Bly-syra
Runtime (upp till)	7 min vid full laddning 26 min vid halv maskin
Laddningstid	3 timmar
Transfertid	2 ms
Egenskaper	Underhållsfri, förseglad, läcksäker

Gränssnitt för fjärradministration	Ethernet, RS-232, USB

Gränssnitt	1 x hantering (RS-232) - RJ-45 1 x hantering (USB) - 4-stifts USB typ B Hantering (USB) - RJ-45
Expansionskortplatser	1 (totalt)/ 0 (ledig) x SmartSlot

Inkluderade tillbehör	Rackmonteringsskenor, temperatursond
Medföljande kablar	Seriell kabel - extern USB-kabel - extern
Rackmonteringssats	Inkluderat
Egenskaper	Hörbart larm, LCD-bildskärm, Automatisk spänningsreglering (AVR), LED-indikatorer, kallstartfunktion, automatiskt självtest, prediktiv felnotifiering, hotswap-batterier, energimätare
Standarder som följs	VDE, IEC 62040-2, RoHS, REACH, EN 62040-2, EAC, RCM, IEC 62040-1, EN 62040-1

Medföljande programvara	APC PowerChute Business Edition

Service och support	Begränsad garanti - 3 år Begränsad garanti - batterier - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	46 dBA

Bredd	43.2 cm
Djup	45.7 cm
Höjd	8.9 cm
Vikt	28.58 kg

Emballagets bredd	59.4 cm
Emballagets djup	60.3 cm
Emballagets höjd	25.1 cm
Emballagets vikt	31.84 kg

Designat för
