APC Smart-UPS 3000VA LCD RM

APC Smart-UPS 3000VA LCD RM - UPS (kan monteras i rack) - AC 230 V - 2700 Watt - 3000 VA - Ethernet, RS-232, USB - utgångskontakter: 9 - 2U - svart - med APC UPS Network Management Card - för P/N: AR3105W, AR3140G, AR3155W, AR3305W, AR3340G, AR3355W, AR40
Tillverkare: APC
Artikelnr: 3933119A
Tillverkarens artikelnummer: SMT3000RMI2UNC
EAN: 731304327707
Leverera till
*
*
Leveranssätt
Namn
Beräknad leverans
Pris
Inga leveransalternativ
Lagerstatus: 88 st i lager
37 535,00 kr
decrease increase

Produktbeskrivning


APC Smart-UPS protects your data by supplying reliable, network-grade power in either traditional Tower or Rack-optimized form factors for space constrained business critical applications. Award winning APC Smart-UPS is the perfect UPS for protecting business critical fileservers (Intel or UNIX based), minicomputers, network switches and hubs, Point of Sale, retail/bank back office and ATMs. Rack Mount versions are the choice for rack optimized servers, server appliances, blade servers, other blade devices and rack-mounted network switches and hubs.




Egenskaper


● Predicitive failure notification - provides early-warning fault analysis ensuring proactive component replacement
● Wide input voltage range - designed for harsh electrical environments to save battery life
● LED indicators - provide easy-to-read status of the unit and utility power conditions
● Boost and Trim Automatic Voltage Regulation (AVR) - eliminates voltage fluctuations as a source of AV signal degradation and component power-supply stress
● High online efficiency - reduces utility costs, generates less heat
● Energy meter - provides actual kilowatt hours of usage for energy conscious users
● Predictive replace battery date - dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning
● Intuitive LCD interface - provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys
● Single switched outlet group - single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding
● Sequenced network shutdown and reboot - customize network shutdown and reboot sequence of connected servers and UPSs
● Outlet group control - turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations
● Adjustable voltage sensitivity - provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications
● Adjustable voltage-transfer points - maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation
● Audible alarms - provides notification of changing utility power and UPS power conditions
● Automatic restart of loads after UPS shutdown - automatically starts up the connected equipment upon the return of utility power
● Automatic self-test - periodic battery self-test ensures early detection of a battery that needs to be replaced
● Cold-start capable - provides temporary battery power when the utility power is out
● Hot-swappable batteries - ensures clean, uninterrupted power to protected equipment while batteries are being replaced
● Network manageable - provides remote power management of the UPS over the network
● Battery failure notification - provides early-warning fault analysis on batteries enabling timely preventive maintenance
● Safety-agency approved - ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment
● Serial connectivity - provides management of the UPS via a serial port
● Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
● User-replaceable batteries - increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
● Intelligent battery management - maximizes battery performance, life, and reliability through intelligent, precision charging
● Frequency and voltage regulation - gives higher application availability by correcting poor frequency and voltage conditions without using the battery
● Intelligent battery management - maximizes battery performance, life, and reliability through intelligent, precision charging
● Power conditioning - protects connected loads from surges, spikes, lightning, and other power disturbances
● Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
● Automatic restart of loads after UPS shutdown - automatically starts up the connected equipment upon the return of utility power
● Automatic self-test - periodic battery self-test ensures early detection of a battery that needs to be replaced
● Disconnected battery notification - warns when a battery is not available to provide backup power
● Network manageable - provides remote power management of the UPS over the network
● Audible alarms - actively let you know if the unit is on battery, if the battery is low or if there is an overload condition
● LED status indicators - quickly understand unit and power status with visual indicators
● Serial connectivity - provides management of the UPS via a serial port
● Disconnected battery notification - warns when a battery is not available to provide backup power




Teknisk specifikation


Allmänt
Typ av enhetUPS - kan monteras i rack
Höjd (U-format)2U
FärgSvart
Kombinerad medAPC UPS Network Management Card
Nätdel
UPS-teknikInteraktiv
InspänningAC 230 V
Inspänningens område (justeringsbart)AC 151 - 302 V
Tillhandahållen frekvens47 - 63 Hz
Erforderlig frekvens50/60 Hz ± 3Hz
Inmatningsanslutningar1
Kontaktdetaljer för uteffekt8 x power IEC 60320 C13
1 x ström IEC 60320 C19
UtspänningAC 230 V ± 5% - 47 - 63 Hz
Effektkapacitet2700 Watt / 3000 VA
UtvågformSinusvåg
SpänningsavledningJa
Energivärdering320 joule
KretsskyddStrömbrytare
Batteri
TeknikBly-syra
Runtime (upp till)3.2 min vid full laddning
11.5 min vid halv maskin
Laddningstid3 timmar
Transfertid4 ms
EgenskaperUnderhållsfri, förseglad, läcksäker
Nätverk
Gränssnitt för fjärradministrationEthernet, RS-232, USB
Expansion/Anslutning
Gränssnitt1 x hantering (RS-232) - RJ-45
1 x hantering (USB) - 4-stifts USB typ B
Hantering (Ethernet) - RJ-45
Expansionskortplatser1 (totalt)/ 0 (ledig) x SmartSlot
Diverse
Inkluderade tillbehörRackmonteringsskenor, temperatursond
Medföljande kablarSeriell kabel - extern
USB-kabel - extern
Strömkabel - extern
RackmonteringssatsInkluderat
EgenskaperHörbart larm, LCD-bildskärm, Automatisk spänningsreglering (AVR), LED-indikatorer, kallstartfunktion, automatiskt självtest, prediktiv felnotifiering, hotswap-batterier, energimätare
Standarder som följsGS, VDE, IEC 62040-2, IRAM, RoHS, WEEE, REACH, EN 62040-2, EAC, RCM, IEC 62040-1, EN 62040-1
Programvara / Systemkrav
Medföljande programvaraAPC PowerChute Business Edition
Tillverkarens garanti
Service och supportBegränsad garanti - 3 år
Begränsad garanti - batterier - 2 år
Miljöparametrar
Min temperatur vid drift0 °C
Max temperatur vid drift40 °C
Luftfuktighet vid drift0 - 95%
Ljudnivå55 dBA
Mått och vikt
Bredd48 cm
Djup68.3 cm
Höjd8.6 cm
Vikt44.19 kg
Mått och vikt (brutto)
Emballagets bredd60 cm
Emballagets djup98 cm
Emballagets höjd25.4 cm
Emballagets vikt51.59 kg
Kompatibilitetsinformation
Designat förP/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF202BLK, ACF400, ACF402, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR201, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3105, AR3105SP, AR3105W, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3180G, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3810, AR3812, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, NBPD0180, NBRK0201, NBRK0320, NBRK0320E, NBRK0551, NBWL0355, NBWL0356A
