Produktbeskrivning

Reduces utlility costs, generates less heat.

The operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.



Egenskaper

High online efficiency
Reduces utlility costs, generates less heat.

Green mode
The operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

LCD status display
Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs.

Cold-start capable
Provides temporary battery power when the utility power is out.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.



Teknisk specifikation

Typ av enhet	UPS - extern
Batterityp	Intern
Färg	Svart

UPS-teknik	Interaktiv
Inspänning	AC 230 V
Inspänningens område	Växelström 180 - 287 V
Inspänningens område (justeringsbart)	Växelström 170 - 300 V
Tillhandahållen frekvens	50 Hz
Erforderlig frekvens	47 - 63 Hz
Inmatningsanslutningar	1 x ström IEC 60320 C20
Kontaktdetaljer för uteffekt	6 x power IEC 60320 C13 1 x ström IEC 60320 C19
Utspänning	AC 230 V ± 5% - 50 Hz
Effektkapacitet	1300 Watt / 2000 VA
Utvågform	Sinusvåg
Energivärdering	300 joule

Antal	1
Teknik	Bly-syra
Runtime (upp till)	20 min vid halv maskin 5 min vid full laddning
Laddningstid	3 timmar
Egenskaper	Underhållsfri, förseglad

Gränssnitt för fjärradministration	USB

Gränssnitt	1 x hantering (USB) - 4-stifts USB typ B

Medföljande kablar	USB-kabel - extern
Egenskaper	Hörbart larm, LCD-bildskärm
Standarder som följs	C-Tick, GOST, SABS, UL 1449, VDE, RoHS, REACH

Service och support	Begränsad garanti - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	45 dBA

Bredd	17 cm
Djup	44 cm
Höjd	21.6 cm
Vikt	27.5 kg

Emballagets bredd	37 cm
Emballagets djup	59 cm
Emballagets höjd	33 cm
Emballagets vikt	30 kg
