Produktbeskrivning

Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The entire Smart-UPS On-Line family provides value to customers with demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.



Egenskaper

Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.

Scalable runtime
It allows additional run time to be quickly added as needed.

Intelligent battery management
It maximizes battery performance, life, and reliability through intelligent, precision charging.

Hot-swappable batteries
It ensures clean, uninterrupted power to protected equipment while batteries are being replaced.

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Temperature-compensated battery charging
It prolongs battery life by regulating the charge voltage according to battery temperature.

Plug-and-Play external batteries
It ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.

Rack/Tower convertible
It protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Flash upgradeable firmware
Install maintenance releases of firmware remotely using FTP.

User-replaceable batteries
It increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Predicitive failure notification
It provides early-warning fault analysis ensuring proactive component replacement.

Disconnected battery notification
It warns when a battery is not available to provide backup power.

Audible alarms
Provides notification of changing utility power and UPS conditions.

Frequency and voltage regulation
It gives higher application availability by correcting poor frequency and voltage conditions without using the battery.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Input power factor correction
It minimizes installation costs by enabling the use of smaller generators and cabling.

Generator compatible
It ensures clean, uninterrupted power to protected equipment when generator power is used.

Cold-start capable
It provides temporary battery power when the utility power is out.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.



Teknisk specifikation

Typ av enhet	UPS - kan monteras i rack
Höjd (U-format)	7U
Färg	Svart

UPS-teknik	Online
Inspänning	AC 230/380 V
Inspänningens område	Växelström 160 - 285/380 - 415 V
Tillhandahållen frekvens	50/60 Hz ± 0.1Hz
Ingångskablage	3-fas / 1-fas
Erforderlig frekvens	40 - 70 Hz
Inmatningsanslutningar	1 x fast 5-trådig (3PH + N + G)
Kontaktdetaljer för uteffekt	1 x fast 5-trådig (3PH + N + G)
Utspänning	AC 230/380 V 50/60 Hz
Effektkapacitet	20000 Watt / 20000 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja
Effektivitet	93% Battery mode

Teknik	Bly-syra
Laddningstid	4 timmar

Gränssnitt för fjärradministration	RS-232

Gränssnitt	1 x hantering (RS-232) - 9 pin D-Sub (DB-9)

Medföljande kablar	Seriell kabel - extern
Standarder som följs	CB, IEC 62040-2, EN 62040-2

Service och support	Begränsad garanti - ersättningsprodukt eller reparation - 3 år Begränsad garanti - batterier - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	58 dBA

Bredd	44 cm
Djup	70 cm
Höjd	30.6 cm
Vikt	142.5 kg

Emballagets bredd	59 cm
Emballagets djup	79 cm
Emballagets höjd	53.5 cm
