Produktbeskrivning

Smart-UPS RT is a family of high performance UPSs for servers, networking equipment, telecommunication systems, industrial and medical equipment, and other mission-critical applications. Smart-UPS RT UPSs are based on the field-proven, industry-leading Smart-UPS functionality, but feature double conversion on-line topology, which delivers tight voltage and frequency regulation, zero transfer time to and from battery, and input power factor correction. While offering advanced performance and high availability features, the Smart-UPS RT can be managed using PowerChute software, as well as an array of SmartSlot accessories. Smart-UPS RT provides battery back up to the load through the use of internal batteries. However, an unlimited number of external battery packs can be added to meet desired levels of runtime. All Smart-UPS RTs and battery packs ship in tower configuration, while easily converting to the 19" rack-mount mode with the addition of an APC Rail Kit.



Teknisk specifikation

Typ av enhet	Transformator - extern
Höjd (U-format)	3U
Stativstorlek	19"
Färg	Svart

Inspänning	AC 230 V
Inspänningens område	AC 220-240 V
Erforderlig frekvens	50/60 Hz
Inmatningsanslutningar	3 x fast
Kontaktdetaljer för uteffekt	3 x fast
Utspänning	AC 230 V
Effektkapacitet	5000 VA
Kretsskydd	Strömbrytare

Rackmonteringssats	Tillval
Standarder som följs	FCC klass A-certifierad, UL, VCCI, C-Tick, BSMI, cUL, EN 60950, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5

Service och support	Begränsad garanti - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Min temperatur vid förvaring	-25 °C
Max temperatur vid förvaring	65 °C
Luftfuktighet vid drift	5 - 95%
Luftfuktighet vid lagring	5 - 95%

Bredd	43.2 cm
Djup	66 cm
Höjd	13 cm
Vikt	56.8 kg

Designat för

P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACF003, ACF201BLK, ACF400, AP7950, AR203A, AR204A, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2500, AR2507, AR2580, AR2587, AR3100, AR3100G, AR3100SP, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140W, AR3150, AR3150SP, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR8135BLK, SMC1500I-2U, SMT1500RMI2UNC, SMT2200RMI2UNC, SMT30002U-BR, SMT3000RMI2UNC, SMT750RMI2UNC, SMX2000LV, SMX2000LVNC, SMX3000HV-BR, SMX3000HVT, SMX3000LV, SMX3000LV2U-BR, SMX750INC, SRC10KUXICH, SU3000RMJ3UOS3, SUA1500R2X93, SUA2200R2X147, SUA3000R2IX38, SUA3000R2X428, SUA3000RMXL3U-BR, SUA750R2IX38, SURT10000XLJ, SURT1000RMXLI, SURT1000RMXLI-NC, SURT1000XLICH, SURT1000XLI-NC, SURT2000RMXLI, SURT3000UXICH, SURT3000XLICH, SURT3000XLI-ET, SURT3000XLIX438, SURT3000XLTW, SURT5000UXICH, SURT5000XLICH, SURT5000XLIX438, SURT5000XLJ, SURT6000RMXLI, SURT6000RMXLI-CC, SURT6000UXICH, SURT6000XLI, SURT6000XLI-CC, SURT6000XLICH, SURT6000XLIM, SURT6000XLT, SURT6000XLT-1TF3, SURT6000XLT-CC, SURT6KRMXL3U-TF5, SURTD2200XLIM, SURTD3000RMXLI, SURTD3000RMXLT3U, SURTD3000XLI, SURTD3000XLIM, SURTD3000XLT, SURTD3000XLT-1TF3, SURTD3KRMXL3U-TF5, SURTD5000RMXLI, SURTD5000XLI, SURTD5000XLI-CC, SURTD5000XLI-ET, SURTD5000XLT-1TF3
