Produktbeskrivning

High density, double-conversion on-line power protection with scalable runtime. A battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance. ECO Mode by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection. Text and mimic diagrams display modes of operation, system parameters, and alarms.



Egenskaper

Low operating and maintenance costs with proven reliability and intelligent battery management
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.

Avoids costly power problems by keeping your IT equipment and data protected and available
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.

Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Save time with easy and convenient remote accessibility
Network manageable via serial or USB. Includes Powerchute Network Shutdown software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.



Teknisk specifikation

Typ av enhet	UPS - Effektfaktorkorrigering (PFC) - rackmonterbar/extern
Färg	Svart

UPS-teknik	Online
Inspänning	AC 230 V
Inspänningens område	Växelström 50 - 150/80 - 150 V
Tillhandahållen frekvens	50/60 Hz ± 3Hz
Erforderlig frekvens	40 - 70 Hz
Inmatningsanslutningar	1 x ström IEC 60320 C14, ström BS 1363A, Eurokontakt (ström CEE 7/16)
Kontaktdetaljer för uteffekt	6 x power IEC 60320 C13
Utspänning	AC 220/230/240 V ± 2% - 50/60 Hz
Effektkapacitet	1000 Watt / 1000 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja
Energivärdering	432 joule
Kretsskydd	Strömbrytare

Teknik	Bly-syra
Runtime (upp till)	8.5 min vid full laddning 21.1 min vid halv maskin 9.8 min vid 900 Watt 13.8 min vid 700 Watts 59.6 min vid 200 Watt
Laddningstid	3 timmar
Egenskaper	Underhållsfri, förseglad, läcksäker

Gränssnitt för fjärradministration	RS-232, USB

Gränssnitt	1 x hantering (RS-232) - RJ-45 1 x EPO (emergency power off) 1 x hantering (USB)
Expansionskortplatser	1 (totalt)/ 1 (ledig) x SmartSlot

Medföljande kablar	Strömkabel 1.83 m USB-kabel - extern
Egenskaper	Hörbart larm, LCD-bildskärm, intern förbikoppling, LED-indikatorer, kallstartfunktion, fast programvara kan uppdateras, automatiskt självtest, hotswap-batterier, Eco-Mode, återställningsbrytare
Standarder som följs	RoHS, REACH, IP20, EAC

Medföljande programvara	APC PowerChute Business Edition

ENERGY STAR	Ja

Service och support	Begränsad garanti - 3 år Begränsad garanti - batterier - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95 % (icke-kondenserande)
Ljudnivå	50 dBA

Bredd	43.2 cm
Djup	50.5 cm
Höjd	8.5 cm
Vikt	20.5 kg

Emballagets bredd	59.4 cm
Emballagets djup	74.9 cm
Emballagets höjd	24.6 cm
Emballagets vikt	29.6 kg
