Produktbeskrivning

Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Network manageable via serial, USB or optional Ethernet. Includes Powerchute Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.

Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.



Egenskaper

Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Save time with easy and convenient remote accessibility
Network manageable via serial, USB or optional Ethernet. Includes Powerchute Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.

Avoids costly power problems by keeping your IT equipment and data protected and available
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.

Low operating and maintenance costs with proven reliability and intelligent battery management
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.



Teknisk specifikation

Typ av enhet	UPS - extern

UPS-teknik	Online
Inspänning	AC 230 V
Inspänningens område	AC 220-240 V
Inspänningens område (justeringsbart)	AC 100 - 275 V
Tillhandahållen frekvens	50/60 Hz
Erforderlig frekvens	40 - 70 Hz
Inmatningsanslutningar	Ström IEC 60320 C20, ström BS 1363A, Eurokontakt (ström CEE 7/16)
Kontaktdetaljer för uteffekt	8 x power IEC 60320 C13 2 x ström IEC 60320 C19
Utspänning	AC 230 V ± 3% - 50/60 Hz
Effektkapacitet	1980 Watt / 2200 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja
Energivärdering	340 joule

Teknik	Bly-syra
Laddningstid	3 timmar
Egenskaper	Underhållsfri, förseglad, läcksäker

Gränssnitt för fjärradministration	RS-232, USB

Gränssnitt	1 x seriell - RJ-45 1 x EPO (emergency power off) 1 x hantering (USB)
Expansionskortplatser	1 (totalt)/ 1 (ledig) x SmartSlot

Medföljande kablar	Strömkabel 2.44 m
Egenskaper	Hörbart larm, nödavstängning, LCD-bildskärm, intern förbikoppling
Standarder som följs	VDE, IEC 62040-2, IP20, EAC, RCM, IEC 62040-1

Medföljande programvara	APC PowerChute Business Edition

ENERGY STAR	Ja

Service och support	Begränsad garanti - 3 år Begränsad garanti - batterier - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95 % (icke-kondenserande)
Ljudnivå	55 dBA

Bredd	8.5 cm
Djup	58.4 cm
Höjd	43.2 cm
Vikt	25 kg

Emballagets bredd	59.9 cm
Emballagets djup	81 cm
Emballagets höjd	24.6 cm
Emballagets vikt	30.84 kg
