Produktbeskrivning

Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.



Egenskaper

Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Avoids costly power problems by keeping your IT equipment and data protected and available
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.

Low operating and maintenance costs with proven reliability and intelligent battery management
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.

Save time with easy and convenient remote accessibility
Network manageable via serial, USB or optional Ethernet. Includes Powerchute Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.



Teknisk specifikation

Typ av enhet	UPS - Effektfaktorkorrigering (PFC) - rackmonterbar/extern
Höjd (U-format)	3U
Färg	Svart

UPS-teknik	Online
Inspänning	AC 220/230/240 V
Inspänningens område	AC 160 - 275 V
Tillhandahållen frekvens	50/60 Hz ± 3Hz
Erforderlig frekvens	40 - 70 Hz
Inmatningsanslutningar	1 x ström IEC 60320 C20
Kontaktdetaljer för uteffekt	6 x power IEC 60320 C13 2 x ström IEC 60320 C19
Utspänning	AC 220/230/240 V ± 2% - 50/60 Hz
Effektkapacitet	1.98 kW / 2200 VA
Utvågform	Sinusvåg
Spänningsavledning	Ja
Energivärdering	432 joule
Kretsskydd	Strömbrytare
Effektivitet	90% at 100% Load

Teknik	Litiumjon
Runtime (upp till)	13 min vid full laddning

Gränssnitt för fjärradministration	RS-232

Gränssnitt	1 x hantering (RS-232) - RJ-45 1 x EPO (emergency power off) 1 x USB - 4-stifts USB typ A
Expansionskortplatser	1 (totalt)/ 1 (ledig) x SmartSlot

Inkluderade tillbehör	Tornställ
Medföljande kablar	Strömkabel 1.83 m USB-kabel - extern
Egenskaper	Hörbart larm, LCD-bildskärm, intern förbikoppling, LED-indikatorer, kallstartfunktion, hotswap-batterier, Eco-Mode, energimätare, automatisk omstart, generatorkompatibel
Standarder som följs	RoHS, REACH, IP20, EAC

Medföljande programvara	APC PowerChute Business Edition

Service och support	Begränsad garanti - 5 år Begränsad garanti - batterier - 5 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95 % (icke-kondenserande)
Ljudnivå	50 dBA

Höjd	43.2 cm
