Produktbeskrivning

APC's Switched Rack Power Distribution Units (PDUs) are premium solutions to many of the power management problems seen in today's IT environments. Some of the problems are unauthorized use of power outlets, locked-up equipment, in-rush current, overloaded circuits, and the need of remote access to power outlets in the rack. The Switched Rack PDUs address these problems through individual outlet control, power on and off delays, current monitoring, alarm thresholds, and network management. Individual outlet control allows users to turn outlets on, turn outlets off, or recycle power to equipment, which can reboot locked-up equipment and avoid unauthorized use of outlets. Power delays allow users to determine the order in which equipment is powered up or down. Utilizing the power delay feature will avoid in-rush current, which can cause overloads. Monitoring the current draw at the rack level is key to avoiding downtime due to overloaded circuits. The Switched Rack PDUs provide an aggregate current draw, which can be viewed remotely or locally, via digital display. In addition, alarms will be generated based on user-defined thresholds to alert users of potential circuit overloads. Users can access, configure, and control the Switched Rack PDUs through Web, SNMP, or Telnet Interfaces.



Egenskaper

Network management
Full-featured network management interfaces that provide standards-based management via Web, SNMP and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.

Remote individual outlet control
Remotely manage outlets so users can turn outlets off that are not in use or recycle power to locked-up equipment.

Power delays
Allows users to configure the sequence in which power is turned on or off for each outlet. This helps avoid in-rushes at start-up, which can cause overloaded circuits and dropped loads. Sequencing also allows users to predetermine which piece of equipment is turned on first so other equipment dependant on that unit will function properly.

Load indicator LED
This indicates overload and warning conditions based on the user-defined alarm thresholds, and alerts users of potential overloaded circuits.

Integrates with InfraStruXure Central
An IT-ready, scalable monitoring system that collects, organizes, and distributes critical alerts, surveillance video and key information, providing a unified view of complex physical infrastructure environments from anywhere on the network.



Teknisk specifikation

Typ av enhet	Grenuttag - kan monteras i rack
Sladdlängd	3.05 m
Färg	Svart

Inspänning	AC 200/208/230 V
Inspänningens område	AC 200-240 V
Inmatningsanslutningar	1 x ström IEC 60320 C14
Kontaktdetaljer för uteffekt	16 x power IEC 60320 C13
Utspänning	AC 230 V
Max elektrisk ström	10 A

Gränssnitt för fjärradministration	Ethernet 10/100
Protokoll för administration på distans	SNMP, Telnet, HTTP

Gränssnitt	1 x hantering (Ethernet) - RJ-45 1 x seriell - RJ-11

Medföljande kablar	Strömkabel 3.05 m
Rackmonteringssats	Inkluderat
Egenskaper	LED-fönster, spänningsmätare
Standarder som följs	GOST, EN 61000-3-2, VDE, EN 61000-3-3, EN55024, IRAM, RoHS, REACH, EN 55022 Class A

Service och support	Begränsad garanti - material och tillverkning - 2 år

Min temperatur vid drift	-5 °C
Max temperatur vid drift	45 °C
Luftfuktighet vid drift	0 - 95%

Bredd	5.6 cm
Djup	4.4 cm
Höjd	124.5 cm
Vikt	4.32 g

Emballagets bredd	15.2 cm
Emballagets djup	12.7 cm
Emballagets höjd	213.4 cm
Emballagets vikt	5.23 kg

Designat för

P/N: AR3355W, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4038IX432, AR9300SP, AR9300SP-R, AR9307SP, AR9307SP-R, NBPD0160A, NBWL0355A, NBWL0356A, SCL400RMJ1U, SCL500RM1UC, SCL500RM1UNC, SCL500RMI1UC, SCL500RMI1UNC, SMC1000-2UC, SMC1000-2UTW, SMC1000-BR, SMC1000I-2UC, SMC1000I-BR, SMC1000IC, SMC15002U-BR, SMC1500-2UC, SMC1500-2UTW, SMC1500-BR, SMC1500I2U-BR, SMC1500I-2UC, SMC1500I-BR, SMC1500IC, SMC2000I2U-BR, SMT1000I-AR, SMT1000IC, SMT1000R2I-AR, SMT1000RM2UC, SMT1000RMI2UC, SMT1500I-AR, SMT1500IC, SMT1500R2I-AR, SMT1500RM2UC, SMT1500RM2UNC, SMT1500RMI2UC, SMT1500RMI2UNC, SMT2200I2U-BR, SMT2200I-AR, SMT2200IC, SMT2200R2I-AR, SMT2200RM2UC, SMT2200RM2UNC, SMT2200RMI2UC, SMT2200RMI2UNC, SMT30002U-BR, SMT3000I2U-BR, SMT3000I-AR, SMT3000IC, SMT3000R2I-AR, SMT3000RM2UC, SMT3000RM2UNC, SMT3000RMI2UC, SMT3000RMI2UNC, SMT750IC, SMT750RM2UC, SMT750RM2UNC, SMT750RMI2UC, SMT750RMI2UNC, SMTL1000RM2UC, SMTL750RM2UC, SMTL750RMI2UC, SMX1000US, SMX1500RMNCUS, SMX1500RMUS, SMX2000LVNCUS, SMX2000LVUS, SMX2200HVNC, SMX2200R2HVNC, SMX2200RMLVUS, SMX2KR2UNCX145, SMX2KRMLVNCUS, SMX3000HV-BR, SMX3000HVTUS, SMX3000LV2U-BR, SMX3000LVNCUS, SMX3000LVUS, SMX3000RMLVUS, SMX3KRMLVNCUS, SMX750INC, SMX750NC, SMX750US, SRC2000XLI-CC, SRC3KUXI, SRT1000RMXLA, SRT1000RMXLA-NC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT10KRMXLT-10KTF, SRT10KRMXLT30, SRT10KRMXLT-5KTF2, SRT10RMXLIX806, SRT1500RMXLA, SRT1500RMXLA-NC, SRT1500RMXLI, SRT1500XLI, SRT2200RMXLA, SRT2200RMXLA-NC, SRT2200RMXLAUS, SRT2200RMXLI, SRT2200RMXLI-NC, SRT2200XLI, SRT2200XLI-KR, SRT3000RMXLA, SRT3000RMXLA-NC, SRT3000RMXLI, SRT3000RMXLI-NC, SRT3000RMXLT, SRT3000RMXLT-5KTF, SRT3000RMXLT-NC, SRT3000RMXLW-IEC, SRT3000XLI, SRT3000XLW-IEC, SRT5KRMXLIM, SRT5KRMXLT-5KTF, SRT5KRMXLTUS, SRT5KRMXLW-TW, SRT6KRMXLIM, SRT6KRMXLT-5KTF, SRT8KRMXLT30, SRT8KRMXLT-5KTF, SUA1000ICH-45, SUA1000RM2UTW, SUA1500I-IN, SUA2200ICH-45, SUA3000I-IN, SURT1000RMXLI-NC, SURT1000XLI-NC, SYAF16KRMICH
