Produktbeskrivning

Engineered to deliver the highest level of business continuity possible, the Symmetra LX uses a modular, redundant architecture that can scale power and run-time as demand increases or when higher levels of availability are required. Advancements in this next generation design greatly decrease foot print or U-space needed in an equipment rack, increase speed and ease of deployment and reduce repair time. With built-in network manageability, the on-line Symmetra LX is the choice to protect high-performance IT and telecom equipment in computer rooms and small data centers.



Egenskaper

Hot-swappable intelligence modules
Ensures clean, uninterrupted power to protected equipment during intelligence module replacement.

Modular design
Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.

Programmable frequency
Ensures compatibility with different input frequencies.

Scalable runtime
Allows additional run time to be quickly added as needed.



Teknisk specifikation

Typ av enhet	Power Array - extern
Höjd (U-format)	13U
Färg	Svart, silver

Batteriteknik som stöds	Bly-syra
Inspänning	AC 220/230/240/380/400/415 V
Inspänningens område	AC 155/276 - 290/480 V
Tillhandahållen frekvens	47 - 63 Hz
Erforderlig frekvens	45 - 65 Hz
Inmatningsanslutningar	1 x fast
Kontaktdetaljer för uteffekt	1 x fast
Utspänning	AC 230 V ± 5% - 47 - 63 Hz
Effektkapacitet	8000 VA
Utvågform	Sinusvåg

Antal	2 (installerad) / 2 (stödd)
Teknik	Bly-syra
Runtime (upp till)	7.5 min vid full laddning
Laddningstid	3 timmar

Gränssnitt för fjärradministration	Ethernet 10/100
Protokoll för administration på distans	SNMP

Gränssnitt	1 x hantering (RS-232) - 9 pin D-Sub (DB-9) 1 x hantering (Ethernet) - RJ-45
Expansionskortplatser	2 (totalt)/ 1 (ledig) x SmartSlot

Egenskaper	Nödavstängning, LCD-display, Hörbart larm
Standarder som följs	C-Tick, GOST, EN 60950, VDE, IEC 60950, EN55024, EN55022 klass A, EN 50091-2

Service och support	Begränsad garanti - 2 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	0 - 95%
Ljudnivå	62 dB

Bredd	48.3 cm
Djup	72.6 cm
Höjd	66 cm
Vikt	202 kg
