Produktbeskrivning

MediaPack 204 VoIP Telephone Adapter, 4 FXS including four FXS lines, SIP, 1 WAN port, 1 LAN port, internal Router with Firewall, including G.711/723.1/726/727/729AB Vocoders



Viktiga egenskaper

AudioCodes MP204B/4S/SIP. Product colour: Blue, Enclosure material: Plastic, LED indicators: LAN, Power, Status, WAN. Voice codecs: CNG, G.168, G.711, G.723.1, G.726, G.727, G.729A, G.729B, VAD. Supported network protocols: IPv4, TCP/UDP, ICMP, ARP, RTP, RTCP, PPPoE, PPTP, L2TP, DNS, Dynamic DNS, STUN, DHCP..., VoIP protocols: SIP(RFC 3261), Supported protocols: SIP. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.1Q, IEEE 802.1p, Modulation: DTMF. WAN connection: Ethernet (RJ-45)



Teknisk specifikation

Product colour	Blue
Enclosure material	Plastic
LED indicators	LAN,Power,Status,WAN

Voice codecs	CNG,G.168,G.711,G.723.1,G.726,G.727,G.729A,G.729B,VAD

Control display unit	Yes

Supported network protocols	IPv4, TCP/UDP, ICMP, ARP, RTP, RTCP, PPPoE, PPTP, L2TP, DNS, Dynamic DNS, STUN, DHCP client/server, NAT, RIP, SPI Firewall, HTTP/HTTPS, FTP/TFTP, SNMP
VoIP protocols	SIP(RFC 3261)
Supported protocols	SIP

Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.1Q,IEEE 802.1p
Differentiated services (DiffServ) supported	Yes
Modulation	DTMF

VLAN support	Yes
Firewall security	Yes

Foreign eXchange Station (FXS) ports quantity	4
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	2

Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes

Input voltage	110 - 220 V
Input frequency	50/60 Hz
Output voltage	12 V
Output current	1 A

Width	167 mm
Height	33 mm
Depth	133 mm

Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-25 - 85 °C
