Produktbeskrivning

The RXV200-B70 bundle includes the AI-powered RXVCam70 dual-lens PTZ camera and provides an ideal solution for a truly immersive meeting experience in large rooms.



Viktiga egenskaper

AudioCodes RXV200 Compute Device for small to mid size meeting rooms. The Bundle also Includes the RXPanel, RX15 Speakerphone and RXVCam50M. Product type: Group video conferencing system, Number of persons: 18 person(s). Sensor type: CMOS. HD type: 4K Ultra HD. Optical zoom: 12x, Digital zoom: 16x. Ethernet LAN, Wi-Fi. Bluetooth. Display diagonal: 20.3 cm (8"), Display resolution: 1280 x 800 pixels. Operating system installed: Android. Product colour: Black



Teknisk specifikation

Product type	Group video conferencing system
Number of persons	18 person(s)
Number of cameras	1
Bluetooth	Yes
Bluetooth version	5.0
Product colour	Black
Signal-to-Noise Ratio (SNR)	55 dB
Pan range	-170 - 170 °
Tilt angle range	-90 - 90 °
PTZ control	Yes

HD type	4K Ultra HD
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	640 x 480 (VGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080),3840 x 2160
Aspect ratio	16:9
Resolution at capture speed	640x480@25fps,640x480@30fps,1280x720@25fps,1280x720@30fps,1920x1080@25fps,1920x1080@30fps,3840x2160@30fps
Video formats supported	H.264,MJPG,YUV

Built-in speaker(s)	Yes
Number of speakers	1
Frequency range	250 - 20000 Hz
Automatic gain control	Yes
RMS rated power	40 W
Microphone pick-up range	8 m

USB connector type	USB Type-A,USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1

Interface module HDMI ports quantity	3
Interface module HDMI input ports quantity	1
Interface module HDMI output ports quantity	2
Interface module Ethernet LAN (RJ-45) ports	1

Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
Networking standards	IEEE 802.1Q,IEEE 802.1p
Supported network protocols	TCP/IP (IPv4)
VLAN support	Yes
Quality of Service (QoS) support	Yes
Security algorithms	256-bit AES

Megapixel (approx.)	8.42 MP
Camera type	Single camera
Zoom capability	Yes
Optical zoom	12 x
Digital zoom	16 x
Sensor type	CMOS
Image sensor size	1/1.8 "
Focal length range	4.8 ~ 57.8 mm
Field of view (wide)	107 °
3D NR (Noise Reduction)	Yes
Camera privacy shutter	Yes
Minimum illumination	0.5 lx
Camera shutter speed	1/30 ~ 1/10000 s
White balance	Auto,Indoor,Manual,Outdoor

Built-in display	Yes
Display diagonal	8 "
Display resolution	1280 x 800 pixels
Touchscreen	Yes

Microphone colour	Black
Microphone sensitivity	38 dB
Microphone frequency	300 - 8000 Hz
Microphone mute	Yes

Computer system type	Mini PC
Processor family	Snapdragon
Processor model	QCS8250
Operating system installed	Android

Cable lock slot	Yes
Cable lock slot type	Kensington

Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Storage relative humidity (H-H)	20 - 90 %
Storage temperature (T-T)	-10 - 60 °C

Power source type	DC
Current	3 A
DC input voltage	12 V

Interface module dimensions (W x D x H)	170 x 170 x 41.3 mm
Interface module weight	750 g
Speaker dimensions (WxDxH)	800 x 56 x 90 mm
Speaker weight	3600 g
Camera dimensions (WxDxH)	295 x 245 x 240 mm
Camera weight	2300 g

Cables included	LAN (RJ-45),USB Type-C
AC adapter included	Yes
Packaging content	✓ RXV200 ✓ RX40 ✓ RXVCam70 ✓ RX-PAD ✓ 12V 3A Power Adapter (100-240V) ✓ USB Type C cable ✓ Ethernet cable
