Produktbeskrivning

Ideal for residential care and small stores, this compact, easy-to-install camera offers two-way audio and great image quality - around the clock. AI-powered, it supports advanced features and powerful video and audio analytics on the edge.

Ensure privacy and security
This fully featured camera is designed with privacy and security in mind. Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations. A tally LED indicates video streaming or recording. And, with AXIS Live Privacy Shield, it’s easy to remotely monitor activities while protecting privacy. Furthermore, AXIS TM1903 Privacy Cover is available as an accessory to temporarily protect privacy when needed. Plus, a built-in pencil privacy filter ensures discreet images that safeguard privacy.

AI-powered analytics
AXIS M1075-L Mk II includes a deep learning processing unit (DLPU) to run advanced features and powerful analytics on the edge. With AXIS Object Analytics preinstalled, it can detect, track, and count humans. It also includes AXIS Audio Analytics, which detects sounds such as breaking glass, screams, shouts, speech, and coughing fits, and provides instant alerts when these events occur. In addition, generated metadata can be gathered and visualized in a dashboard for valuable insights.

Extended possibilities
This compact camera supports PoE and includes a USB and I/O port for optional Wi-Fi-dongle connectivity. The I/O port also allows you to connect external devices, such as a panic button - ideal in elderly care facilities and small stores. It can be mounted in corners for complete coverage with a 103° field of view and features a built-in speaker and dual microphones. Plus, voice enhancer ensures great two-way audio communication. With an IR-corrected lens, it offers professional-quality video both day and night. What’s more, a passive infrared (PIR) sensor can detect movement in total darkness. And an HDMI port lets you display live video on a public viewing monitor.



Viktiga egenskaper

Axis M1075-L Mk II. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Box. Minimum illumination: 0.18 lx, Lens viewing angle, horizontal: 103°, Lens viewing angle, vertical: 55°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Detect distance: 42 m, Observe distance: 16 m, Recognize distance: 8 m



Teknisk specifikation

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
People counting function	Yes
Wide Dynamic Range (WDR)	Yes
Infrared (IR) cut-off filter	Yes
Day/night mode	Yes
Alarm input/output	Yes
Built-in processor	Yes
Processor model	Ambarella CV25
Dynamic range	120 dB

Form factor	Box
Mounting type	Ceiling/wall
Product colour	White
LED indicators	Yes
Housing material	Aluminium,Plastic
International Protection (IP) code	IP40

Minimum illumination	0.18 lx
Lens viewing angle, horizontal	103 °
Lens viewing angle, vertical	55 °
Camera pixel size	2.8 µm
Camera shutter speed	1/19000 - 1/5 s

Sensor type	CMOS
Optical sensor size	1/2.9 "
Progressive scan	Yes

Zoom capability	Yes
Detect distance	42 m
Observe distance	16 m
Recognize distance	8 m
Maximum aperture number	2
Identify distance	4 m
Fixed focal length	3.16 mm

Night vision	Yes
Night vision distance	18 m
LED type	IR
Infra-red wavelength	850 nm

Maximum resolution	1920 x 1080 pixels
Total megapixels	2 MP
Video compression formats	H.264H,H.264M,H.265
Video recording	Yes
Frame rate	30 fps
Video streaming	Yes
Image quality adjustment	Saturation,Contrast,Brightness,Sharpness,White balance

Built-in speaker(s)	Yes
Audio system	2-way
Audio formats supported	AAC-LC,LPCM,G.711,PCM,ADPCM,OPUS
Built-in microphone	Yes

Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	Yes
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.1x,IEEE 802.1AE,IEEE 802.1ar,IEEE 802.3af,IEEE 802.3at
Quality of Service (QoS) support	Yes

Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Flash memory	1024 MB
RAM capacity	2048 MB

Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
Terminal block port	Yes

Alarm input channels	1
Alarm output channels	1
Active tampering alarm	Yes
Network access storage (NAS)	Yes
HTTPS encryption	Yes
Video motion detection	Yes

Cloud-managed	Yes

Power source type	PoE
Power consumption (typical)	5.4 W
Power consumption (max)	12.95 W

Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 85 %
Storage relative humidity (H-H)	5 - 95 %

Width	60 mm
Depth	93 mm
Height	105 mm
Weight	153 g

Number of cameras	1
Mounting kit	Yes
Manual	Yes
