Produktbeskrivning

With its 6 MP sensor, AXIS M3077-PLVE offers excellent image quality and a complete 180° or 360° overview, indoors or out, around the clock. It features two built-in microphones allowing for audio surveillance and detection. This compact mini dome offers dewarped views such as panorama, quad, corner, and corridor views directly from the camera. It includes Axis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. And, Axis OptimizedIR for surveillance in pitch darkness.



Viktiga egenskaper

Axis 02018-001. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Angle of rotation: 180°, Lens viewing angle, horizontal: 183°, Lens viewing angle, vertical: 183°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Focal length range: 1.56 mm



Teknisk specifikation

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
PTZ modes	Digital PTZ
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Dynamic range	120 dB
Number of languages	12
Languages support	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,POL,POR,RUS

Form factor	Dome
Mounting type	Ceiling/wall
Product colour	White
Housing material	Aluminium,Polycarbonate (PC)
International Protection (IP) code	IP66
IK code	IK10

Angle of rotation	180 °
Lens viewing angle, horizontal	183 °
Lens viewing angle, vertical	183 °
Camera shutter speed	1/16000 - 1 s

Sensor type	CMOS
Optical sensor size	1/1.8 "

Number of lenses	1
Zoom capability	Yes
Focal length range	1.56 mm
Fixed focus	Yes
Focus adjustment	2.0

Night vision	Yes
LED type	IR

Maximum resolution	2560 x 1920 pixels
Video compression formats	H.264,H.265,M-JPEG,MPEG4
Supported graphics resolutions	256 x 144,384 x 288,1920 x 1440,2560 x 1440,2560 x 1920
Video recording	Yes
Frame rate	60 fps
Video intelligence analytic	Yes
Thermal frame rate (NTSC)	50 - 60 Hz
Video streaming	Yes
Noise reduction	Yes
Text caption overlay	Yes

Audio system	1-way
Audio input channels	2.0 channels
Audio formats supported	G.711,G.726,LC-AAC,LPCM,OPUS
Sample rate	48 kHz
Built-in microphone	Yes

Ethernet LAN	Yes
Networking standards	IEEE 802.3af,IEEE 802.3at
Supported network protocols	IPv6 USGv6, HTTP, HTTPSa , HTTP/2, SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, SIP, LLDP, MQTT v3.1.1, Sys

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash),MicroSDHC,MicroSDXC
Flash memory	512 MB
Internal memory	1024 MB

Ethernet LAN (RJ-45) ports	1

Security algorithms	EAP-TLS,HTTPS
Alert notification type	E-mail,Text alert message
Pixel counter	Yes
HTTPS encryption	Yes

Power source type	PoE
Power consumption (typical)	8 W
Power consumption (max)	11.9 W
Power consumption (Power over Ethernet (PoE))	8 W

Operating temperature (T-T)	-40 - 50 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 100 %
Storage relative humidity (H-H)	5 - 95 %

Height	66 mm
Diameter	149 mm
Weight	700 g

Number of cameras	1
Mounting brackets included	Yes

Harmonized System (HS) code	85258900
