Produktbeskrivning
AXIS P1265 Network Camera is a cost-effective complete modular pinhole camera with HDTV 1080p resolution, ideal for discreet indoor eye-level surveillance. It can be installed in tight places or flush-mounted in a wall, ceiling, or metal panel with only a small pinhole lens visible, suitable in, for example, ATMs or vending machines. Equipped with WDR – Forensic Capture, enables the camera to handle scenes with strong variations in light. AXIS P1265 comes with a mounting bracket and an 8 meter (26 feet) detachable cable.
Viktiga egenskaper
Axis 0927-001. Type: IP security camera, Connectivity technology: Wired, Certification: 55032 B, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B B, VCCI B, RCM AS/NZS CISPR 32, ICES-003.... Product colour: White, Form factor: Covert, Housing material: Aluminium, Plastic, Steel. Minimum illumination: 0.27 lx, Lens viewing angle, horizontal: 91°, Lens viewing angle, vertical: 45°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Fixed focal length: 3.7 mm
Teknisk specifikation
Performance
| Type | IP security camera |
|---|
| Connectivity technology | Wired |
|---|
| Wide Dynamic Range (WDR) | Yes |
|---|
| Certification | 55032 B, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B B, VCCI B, RCM AS/NZS CISPR 32, ICES-003 B, KCC KN32 B, KN35, IEC/EN/UL 62368-1, EN 50581, IEC 60529 IP3X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC 60068-2-6, IEC 60068-2-27 |
|---|
Design
| Form factor | Covert |
|---|
| Product colour | White |
|---|
| Housing material | Aluminium,Plastic,Steel |
|---|
Camera
| Minimum illumination | 0.27 lx |
|---|
| Lens viewing angle, horizontal | 91 ° |
|---|
| Lens viewing angle, vertical | 45 ° |
|---|
| Camera shutter speed | 1/32500 - 1/25 (50 Hz), 1/32500 - 1/30 (60 Hz) s |
|---|
Image sensor
| Sensor type | CMOS |
|---|
| Optical sensor size | 1/3 " |
|---|
| Progressive scan | Yes |
|---|
Lens system
| Maximum aperture number | 2.5 |
|---|
| Fixed focal length | 3.7 mm |
|---|
Video
| Maximum resolution | 1920 x 1080 pixels |
|---|
| Video compression formats | H.264,M-JPEG |
|---|
| Supported video modes | 1080p |
|---|
| Video streaming | Yes |
|---|
| Image quality adjustment | Brightness,Colour depth,Contrast,Sharpness |
|---|
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR),Variable Bit Rate (VBR) |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Wi-Fi | No |
|---|
| Bluetooth | No |
|---|
| Ethernet interface type | Fast Ethernet |
|---|
| Networking standards | IEEE 802.3af,IEEE 802.3at |
|---|
| Supported network protocols | IPv4/v6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
|---|
| Cabling technology | 10/100Base-T(X) |
|---|
| Quality of Service (QoS) support | Yes |
|---|
Storage
| Built-in HDD | No |
|---|
| Card reader integrated | Yes |
|---|
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
|---|
| Flash memory | 256 MB |
|---|
| Internal memory | 512 MB |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Interface | RJ-45 |
|---|
Security
| Password protection type | User |
|---|
| HTTPS encryption | Yes |
|---|
| Video motion detection | Yes |
|---|
| Alert notification type | E-mail |
|---|
| IP address filtering | Yes |
|---|
| Security algorithms | HTTPS,SNMP,SNMPv3,SSH,SSL/TLS |
|---|
Management features
| Web-based management | Yes |
|---|
Power
| Power source type | PoE |
|---|
| Power consumption (typical) | 2.5 W |
|---|
| Power consumption (max) | 4 W |
|---|
| Power over Ethernet (PoE) | Yes |
|---|
Operational conditions
| Operating temperature (T-T) | -20 - 50 °C |
|---|
| Storage temperature (T-T) | -40 - 65 °C |
|---|
Packaging content
| Number of cameras | 1 |
|---|
| User guide | Yes |
|---|
Logistics data
| Harmonized System (HS) code | 85258900 |
|---|
