Produktbeskrivning

Built on ARTPEC-9, this indoor AI-powered dome camera with support for AV1 codec delivers excellent 2 MP image quality in any light conditions. It offers accelerated performance to run impressive analytics applications on the edge.

Excellent image quality
AXIS P3275-LV offers excellent image quality and forensic details in 2 MP under any light conditions. Thanks to Lightfinder 2.0 and Forensic WDR, it ensures true colors and great detail in near darkness or challenging light. And OptimizedIR enables surveillance in pitch darkness without the need for extra lighting. Axis Zipstream with support for AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. Furthermore, this dome camera features a built-in audio jack, so it’s possible to connect a microphone for audio support.

Powerful analytics
Featuring a deep learning processing unit (DLPU), this AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics to detect, classify, track, and count humans. Now combined with ARTPEC 9, this application offers enhanced performance with greater accuracy. In addition, AXIS Image Health Analytics comes preinstalled, so you’ll be notified if your image is blocked, degraded, under-exposed, or redirected. And, with AXIS Live Privacy Shield, it’s easy to remotely monitor activities while protecting privacy.

Robust with strong security
This robust, IK10- and NEMA 4X-rated camera is both vandal- and impact-resistant. And a built-in intrusion switch can detect tampering. Axis Edge Vault, our hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. It also offers secure key storage with FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. What’s more, this dome camera is easy to install, maintain, and operate.



Viktiga egenskaper

Axis P3275-LV. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Dome. Minimum illumination: 0.02 lx, Angle of rotation: 95°, Lens viewing angle, horizontal: 100 - 32°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Focal length range: 3.4 - 9.8 mm, Detect distance (wide): 48 m, Detect distance (tele): 135 m



Teknisk specifikation

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
PTZ control	Yes
Wide Dynamic Range (WDR)	Yes
Infrared (IR) cut-off filter	Yes
Day/night mode	Yes
Alarm input/output	Yes
Built-in processor	Yes
Processor model	ARTPEC-9
Dynamic range	120 dB

Form factor	Dome
Mounting type	Ceiling/Wall/Pole
Product colour	White
LED indicators	Yes
Housing material	Plastic,Polycarbonate (PC)
International Protection (IP) code	IP54
IK code	IK10

Camera pan control	Yes
Camera tilt control	Yes
Minimum illumination	0.02 lx
Angle of rotation	95 °
Lens viewing angle, horizontal	100 - 32 °
Lens viewing angle, vertical	52 - 18 °
Tilt angle range	-45 - 80 °
Pan range	-190 - 190 °
Camera pixel size	2.9 µm
Camera shutter speed	1/37000 - 2 s

Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 "
Progressive scan	Yes

Zoom capability	Yes
Focal length range	3.4 - 9.8 mm
Auto focus	Yes
Minimum aperture number	1.4
Maximum aperture number	2.7
Identify distance (tele)	14 m
Identify distance (wide)	4.8 m
Detect distance (tele)	135 m
Detect distance (wide)	48 m
Observe distance (tele)	54 m
Observe distance (wide)	19 m
Recognize distance (wide)	9.6 m
Recognize distance (tele)	27 m

Night vision	Yes
Night vision distance	40 m
LED type	IR
Infra-red wavelength	850 nm

Maximum resolution	1920 x 1080 pixels
Total megapixels	2 MP
Video compression formats	AV1,H.264,H.265,M-JPEG
Video recording	Yes
Frame rate	60 fps
Video streaming	Yes
Noise reduction	Yes
Noise reduction technology	2D noise reduction,3D noise reduction
Gain control type	Auto
Text caption overlay	Yes
Image quality adjustment	Brightness,Contrast,Saturation,Sharpness,White balance

Audio system	2-way
Audio system full duplex	Yes

Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.1AE,IEEE 802.1ar,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at
Quality of Service (QoS) support	Yes

Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash),MicroSDHC,MicroSDXC
Flash memory	8192 MB
RAM capacity	2048 MB

Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Terminal block port	Yes
DC-in jack	Yes

Video motion detection	Yes
Pixel counter	Yes
Network access storage (NAS)	Yes

Cloud-managed	Yes

Power source type	DC,PoE
Power consumption (typical)	3.4 W
Power consumption (max)	10 W
DC output voltage	12
DC output current	0.025 A

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 85 %
Storage relative humidity (H-H)	5 - 95 %

Weight	800 g

Number of cameras	1
Mounting kit	Yes
Manual	Yes
