Produktbeskrivning

Excellent image quality

AXIS P3285-LVE offers excellent image quality and forensic details in 2 MP under any light conditions. Thanks to Lightfinder 2.0 and Forensic WDR, it ensures true colors and great detail in near darkness or challenging light. And OptimizedIR enables surveillance in pitch darkness without the need for extra lighting. Axis Zipstream with support for AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. Furthermore, this dome camera is available with either a high-performing and light-sensitive 10 mm lens or a powerful and flexible 29 mm tele lens for surveillance from a distance.

Powerful analytics

Featuring a deep learning processing unit (DLPU), this AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. Now combined with ARTPEC 9, this application offers enhanced performance with greater accuracy. With an acoustic sensor and support for AXIS Audio Analytics, you be notified whenever something relevant happens, even when there's no visual indication. For instance, it can detect screams, shouts, as well as changes in sound level. Additionally, AXIS Live Privacy Shield makes it easy to remotely monitor activities while protecting privacy.

Robust with strong security

This robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant. It has an operating temperature range from -40°C to 50 °C (-40°F to 122°F). And a built-in intrusion switch can detect tampering. Axis Edge Vault, our hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. It also offers secure key storage with FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. What’s more, this dome camera is easy to install, maintain, and operate.



Viktiga egenskaper

Axis P3285-LVE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.02 lx, Angle of rotation: 190°, Lens viewing angle, horizontal: 29.1°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Lens diameter: 2.9 cm, Focal length range: 10.8 - 28.2 mm, Detect distance (wide): 149 m



Teknisk specifikation

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
PTZ control	Yes
PTZ modes	Digital PTZ
Auto-tracking	Yes
Tour recording	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Certification	UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC

Form factor	Dome
Mounting type	Ceiling/wall
Product colour	Black,White
LED indicators	Yes
Housing material	Plastic,Polycarbonate (PC)
Protection features	Impact resistant,Vandal proof
International Protection (IP) code	IP66
IK code	IK10
Weatherproof	Yes

Camera pan control	Yes
Camera tilt control	Yes
Minimum illumination	0.02 lx
Angle of rotation	190 °
Lens viewing angle, horizontal	29.1 °
Lens viewing angle, vertical	16.4 °
Tilt angle range	-45 - 80 °
Pan range	-190 - 190 °
Camera pixel size	2.9 µm
Camera shutter speed	1/37000 - 2 s

Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 "

Number of lenses	1
Zoom capability	Yes
Lens diameter	29 mm
Focal length range	10.8 - 28.2 mm
Auto focus	Yes
Maximum aperture number	1.76
Minimum aperture number	1.7
Closest focusing distance	3 m
Recognize distance (tele)	79 m
Detect distance (tele)	394 m
Observe distance (wide)	59 m
Identify distance (wide)	15 m
Identify distance (tele)	39 m
Recognize distance (wide)	30 m
Detect distance (wide)	149 m
Observe distance (tele)	157 m

Night vision	Yes
Night vision distance	45 m
LED type	IR
Infra-red wavelength	850 nm

Maximum resolution	1920 x 1080 pixels
Total megapixels	2 MP
Video formats supported	AV1,AVC,H.264,H.265,HEVC,M-JPEG,MPEG4
Supported graphics resolutions	1280 x 800 (WXGA),1440 x 1080,1920 x 1080 (HD 1080)
Frame rate	60 fps
Video streaming	Yes
Noise reduction technology	2D noise reduction,3D noise reduction
Image quality adjustment	Brightness,Contrast,Saturation,Sharpness
Bit rate control	Variable Bit Rate (VBR)
Text caption overlay	Yes
Flip & mirror	Yes

Signal-to-Noise Ratio (SNR)	55 dB
Audio detection	Yes

Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.1AE,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at
Supported network protocols	IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6,
Streaming method	Multicast

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash),MicroSDHC,MicroSDXC
Flash memory	8000 MB
RAM capacity	2000 MB

Ethernet LAN (RJ-45) ports	1
Terminal block port	Yes

Alert notification type	E-mail
Security algorithms	256-bit AES-XTS,EAP-TLS,HTTPS,MSCHAPv2,PEAP
Privacy protection	Yes
Video motion detection	Yes
Pixel counter	Yes
Active tampering alarm	Yes
Human and vehicle targets classification	Yes

Behavior analysis	Line crossing detection

Power source type	PoE
Power consumption (typical)	3.4 W
Power consumption (max)	10 W

Operating temperature (T-T)	-40 - 50 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 100 %
Storage relative humidity (H-H)	5 - 95 %

Width	183 mm
Depth	156 mm
Height	149 mm
Weight	860 g

Number of cameras	1
Sun shield included	Yes
Manual	Yes

Compliance certificates	REACH,RoHS,Trade Agreements Act (TAA)
Doesn't contain	CFR,PVC,PVC/BFR
