Produktbeskrivning

Ideal for wide-area surveillance, this multidirectional camera delivers excellent overviews and detailed coverage. With highly efficient power consumption, it ensures sustainable surveillance with lower operating costs.

Wide area surveillance with high-quality overview—24/7
AXIS P3738-PLE offers four channels with 4K per channel at 15 fps letting you capture both wide-angle and zoomed-in, detailed views. It includes day/night functionality and 360° IR illumination with individually controllable LEDs and a removable IR cut filter. So, you’ll enjoy clear, reflection-free footage and excellent image quality even in low light or complete darkness. Plus, Forensic WDR ensures clarity when there’s both dark and light areas in the scene. Furthermore, it’s possible to run metadata and AXIS Object Analytics streams on multiple channels so you can detect and classify people and vehicles, for instance entering a user-defined area. This makes it possible to count selected objects in an area of interest and trigger an alarm if a threshold is exceeded.

Brilliant Design
This compact camera offers various mounting options. For instance, it can be recessed mounted for discreet surveillance or mounted in ceilings for complete 360° coverage. When mounted on corners, it offers 270° coverage. Featuring a tamper-resistant casing and integrated IP66-/IP67-rated weather shield, it’s protected against rain, snow, and sunlight—ideal for outdoor wall mounting. In addition, all four varifocal camera heads can be moved and rotated to provide the optimal field of view. Plus, each head can be controlled individually so you can monitor scenes in four directions. The camera’s sensors can also be twisted, so two camera heads can be positioned closer together where one captures the wide view and the other zooms in on the same target.

Cost-efficient and secure
With four camera heads in one camera, AXIS P3738-PLE ensures fast, accurate, and cost-effective installation. That’s because there’s only one camera to install, one cable to draw, one IP address, and one video management software (VMS) license. Plus, it offers market-leading energy consumption compared to multiple single-sensor cameras—even with IR enabled. This ensures sustainable surveillance with lower operating costs. Thanks to remote zoom and focus capabilities, it eliminates the need for hands-on fine-tuning. Furthermore, Axis Zipstream significantly lowers bandwidth and storage requirements. And Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access

Deep learning analytics
Built on ARTPEC-8, this high-performance camera features a deep learning processing unit (DLPU) eliminating the need for expensive servers and allowing for a faster and more scalable system. Plus, it improves processing capabilities so you can collect and analyze even more data than before—on the edge. This helps ensure fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, it can detect and classify people and vehicles. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge available from Axis and our partners.



Viktiga egenskaper

Axis P3738-PLE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Angle of rotation: 100°, Lens viewing angle, horizontal: 108 - 40°, Lens viewing angle, vertical: 55 - 23°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Maximum resolution (panoramic camera): 3840 x 2160 pixels, Focal length range (panoramic camera): 3.2 - 8.1 mm



Teknisk specifikation

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Remote viewing	Yes

Form factor	Dome
Mounting type	Ceiling
Product colour	White
International Protection (IP) code	IP66, IP67
IK code	IK09

Minimum illumination	0 lx
Angle of rotation	100 °
Lens viewing angle, horizontal	108 - 40 °
Lens viewing angle, vertical	55 - 23 °
Lens viewing angle, diagonal	131 - 46 °
Tilt angle range	25 - 95 °
Pan range	-90 - 90 °
Camera pixel size	1.45 µm

Sensor type	CMOS
Number of sensors	4
Optical sensor size	1/2.8 "
Progressive scan	Yes

Maximum resolution (panoramic camera)	3840 x 2160 pixels
Focal length range (panoramic camera)	3.2 - 8.1 mm

Number of lenses	4
Zoom capability	Yes
Auto focus	Yes

Night vision	Yes
LED type	IR

Maximum resolution	3840 x 2160 pixels
Video formats supported	H.264,H.265,M-JPEG
Video recording	Yes
Frame rate	15 fps
Video streaming	Yes

Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Networking standards	IEEE 802.1x
Live view	Yes

Flash memory	8192 MB
Internal memory	4096 MB

Ethernet LAN (RJ-45) ports	1

HTTPS encryption	Yes

Power source type	PoE

Operating temperature (T-T)	-30 - 50 °C
Storage temperature (T-T)	-40 - 65 °C

Weight	2000 g

Number of cameras	1

Compliance certificates	CE,EAC,KC,RoHS,UKCA,VCCI,cUL
Sustainability certificates	UL ECOLOGO
Sustainability compliance	Yes
