Produktbeskrivning

Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for powering network products. A midspan injects power and data to the network device with built-in PoE support. No need to replace existing Ethernet switches and cabling infrastructure. AXIS Power over Ethernet Midspan 8-port supports 8 network devices at the same time for cost-effective installation. The multi-port midspan delivers up to 15.4 W per port and is IEEE 802.3af compliant, which ensures compatibility with most Axis products that have built-in support for PoE.



Viktiga egenskaper

Axis 5012-002. Ethernet interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3af. Product colour: White. Power over Ethernet (PoE) voltage: 48 V, Input voltage: 90 - 264 V, Input frequency: 47 - 63 Hz. Width: 438 mm, Depth: 228 mm, Height: 44.5 mm



Teknisk specifikation

Ethernet interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Power over Ethernet (PoE)	Yes
Networking standards	IEEE 802.3,IEEE 802.3af
Cable types supported	Cat5e

Product colour	White
Rack mounting	Yes
Plug and Play	Yes
Auto-sensing	Yes

Ethernet LAN (RJ-45) ports	16
RJ-45 input ports	8
RJ-45 output ports	8

Power over Ethernet (PoE) voltage	48 V
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Input current	4.5 A
Power over Ethernet (PoE) power per port	15.4 W

Operating temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	32 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Width	438 mm
Depth	228 mm
Height	44.5 mm
Weight	4100 g

Harmonized System (HS) code	85176990
