Produktbeskrivning

Built on ARTPEC-9, this AI-powered block camera offers accelerated performance and lets you run impressive analytics applications on the edge. Available with a wide (4.7-10 mm) lens, it features a built-in wiper to withstand harsh outdoor environments.

Superior image quality
AXIS Q1726-LE offers 4 MP resolution at 60 fps and features a large 1/1.8" sensor to ensure consistent performance even in low light. Thanks to Lightfinder 2.0 and Forensic WDR, it delivers true colors and great forensic detail in challenging light or near darkness. Axis Zipstream with support for AV1, H.264, and H.265 significantly lowers bandwidth and storage requirements. What’s more, it’s available with a wide (4.7-10 mm) lens with a 101.8°-44° horizontal field of view for surveillance in wide, open areas. Plus, the built-in lens with remote zoom and focus is perfectly calibrated to save you time and effort.

For harsh, outdoor environments
Ideal for any outdoor location, AXIS Q1726-LE comes with a built-in wiper and front window with carbon nanotube film heater to guarantee great images even in snow, rain, ice, and fog. It can operate in temperatures from -40 °C to 60 °C (-40 °F to 140 °F). And it can withstand winds up to 60 m/s (134 mph). This future-proof camera has a standardized enclosure design that can be reused with any Axis block camera. This makes it a more efficient and environmentally friendly option and ensures you get the full value from your investment. What’s more, the front glass is IK08-rated, and the enclosure is IK10-, NEMA 4X-, NEMA TS-2-, IP66-, and IP67-rated to withstand harsh weather conditions and impacts.

ARTPEC-9 for unmatched performance
ARTPEC-9 refines the remarkable features and capabilities that characterized previous generations of our in-house-designed SoC: low bitrate, AI-powered analytics, superior imaging, and built-in cybersecurity. It also introduces AV1, an open-source video encoding standard from the Alliance for Open Media. With support for AV1 and enhanced image processing, ARTPEC-9 delivers high-quality video with uncompromised detail and clarity, and best-in-class bitrate. Together with Axis Zipstream, AV1 also ensures hassle-free video both on-prem and in the cloud. What’s more, ARTPEC-9 powers advanced analytics applications that detect objects earlier and analyze events more precisely.

Powerful with strong security
Featuring a deep learning processing unit (DLPU), this AI-based camera lets you run advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. With AXIS Image Health Analytics preinstalled, you’ll be notified if your image is blocked, degraded, under exposed, or redirected. Furthermore, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations.



Viktiga egenskaper

Axis Q1726-LE Block Camera. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Box. Lens viewing angle, horizontal: 101.8 - 44°, Lens viewing angle, vertical: 54 - 24.6°, Camera pixel size: 2.9 µm. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Optical zoom: 2.17x, Focal length range: 4.7 - 10 mm, Focus: Motorized



Teknisk specifikation

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
PTZ control	Yes
PTZ modes	Digital PTZ
Preset points	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Dynamic range	120 dB
Languages support	Multi

Form factor	Box
Mounting type	Ceiling/Wall/Pole
Product colour	White
Housing material	Plastic,Aluminium
Protection features	Vandal proof,Wind resistant
International Protection (IP) code	IP66, IP67
IK code	IK10
Fog proof	Yes

Camera pan control	Yes
Camera tilt control	Yes
Minimum illumination	0 lx
Lens viewing angle, horizontal	101.8 - 44 °
Lens viewing angle, vertical	54 - 24.6 °
Camera pixel size	2.9 µm
Camera shutter speed	1/49500 - 2 s

Sensor type	CMOS
Optical sensor size	1/1.8 "

Number of lenses	1
Zoom capability	Yes
Optical zoom	2.17 x
Focal length range	4.7 - 10 mm
Auto focus	Yes
Focus	Motorized
Maximum aperture number	1.2
Minimum aperture number	1.1
Observe distance (wide)	26 m
Recognize distance (tele)	28 m
Recognize distance (wide)	13 m
Observe distance (tele)	56 m
Normal focusing range	0.5 - m
Identify distance (wide)	6.4 m
Detect distance (wide)	65 m
Identify distance (tele)	14 m
Detect distance (tele)	141 m

Night vision	Yes
Night vision distance	50 m
LED type	IR

Maximum resolution	2688 x 1512 pixels
Total megapixels	4 MP
Video compression formats	H.264,H.265,AV1
Supported graphics resolutions	2688 x 1512
Supported video modes	1512p
Frame rate	120 fps
Video streaming	Yes
Noise reduction	Yes
Noise reduction technology	2D noise reduction,3D noise reduction
Gain control type	Auto
Image stabilizer	Yes
Image quality adjustment	Contrast
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Signal-to-Noise Ratio (SNR)	55 dB
Built-in microphone	No
Audio detection	Yes

Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet interface type	Fast Ethernet,Gigabit Ethernet
Networking standards	IEEE 802.1x,IEEE 802.3af,IEEE 802.3at,IEEE 802.1AE,IEEE 802.1ar
Supported network protocols	IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2 , HTTP/ 2, TLS2 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHC
Cabling technology	10/100/1000Base-T(X)

Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash),MicroSDXC,MiniSDHC
Flash memory	8 MB
Internal memory	4 MB

Ethernet LAN (RJ-45) ports	1
RS-422 ports	1
RS-485 ports	1
Microphone in	Yes
DC-in jack	Yes

Alarm input channels	4
Alarm output channels	4
Active tampering alarm	Yes
Privacy protection	Yes
Video motion detection	Yes
HTTPS encryption	Yes

Power source type	PoE,DC
Power consumption (typical)	6.9 W
Power consumption (max)	25.5 W
Power consumption (Power over Ethernet (PoE))	7.7 W
DC output voltage	10,28

Operating temperature (T-T)	-40 - 60 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 100 %
Storage relative humidity (H-H)	5 - 95 %

Width	178 mm
Depth	441 mm
Height	303 mm
Weight	4844 g

Number of cameras	1

Compliance certificates	RoHS,Electromagnetic Compatibility (EMC),CE,EAC,Federal Communications Commission (FCC),ICES,RCM,UL,VCCI,Trade Agreements Act (TAA),REACH
Doesn't contain	Lead,Mercury (element),Cadmium
Suitable for outdoor use	Yes
Iris	Yes
