Produktbeskrivning

This 8-channel standalone appliance includes everything you need to run your complete surveillance system such as AXIS Camera Station Pro licenses, an 8-port PoE switch, and 4 TB of storage. It comes with pre-loaded software and tools to minimize installation time.

Powerful and versatile
This standalone appliance is compact and silent and won’t disturb local operations, ideal for example, in coffee shops, retail stores, and offices. With eight channels and AXIS Camera Station Pro licenses included, it gives you complete control, and you can run your entire solution on-premises. It comes with one empty bay for easy storage expansion, and support for AXIS Camera Station Cloud Storage if recording in the cloud is preferred. Built using powerful components, it supports AI applications such as Smart search 2. Furthermore, the built-in switch features an additional uplink port for easy and cost-efficient system expansion using AXIS S30 Recorder Series.

Easy to install and maintain
It comes preloaded with software and tools to help you set up and maintain your system. For instance, AXIS Recorder Toolbox includes an intuitive wizard to set up hostname, network settings, and date and time settings. It also includes a dashboard providing information on the built-in switch including uptime, current configuration, and basic settings. This all-in-one device provides everything you need to support your operations and update and maintain your system — all from one supplier. What’s more, advanced replacement service (RMA) and a 5-year hardware warranty ensure trouble-free ownership and better control over total costs.

Created with cybersecurity in mind
This reliable recording solution offers high-security features and standards. It includes an encrypted operating system and recordings with a FIPS 140-2 Level 2 certified TPM. Produced in a TAA-designated country, this appliance complies with NDAA FY19 and FY2023 and comes with a Software Bill of Materials (SBOM), ensuring compliance with strict regulations. Secure boot protects the system and ensures the recorder only runs a trusted operating system. Furthermore, the connected devices are physically isolated from the external network, reducing the risk of cyberattacks from the corporate network or the internet.



Viktiga egenskaper

Axis S2208 Mk II 4 TB. Video input channels: 8 channels, Maximum resolution: 7680 x 4320 pixels, Internal memory: 16 MB. HDD capacity: 4 GB, Maximum storage capacity: 8 TB, HDD interface: SATA. Networking standards: IEEE 802.3at. Brand compatibility: Ajax, Product colour: Black, Certification: UL/cUL, BIS, CE, KC, VCCI, RCM, BSMI, FCC, NOM. Power consumption (max): 270 W, Power consumption (typical): 75 W, AC input voltage: 100 - 240 V



Teknisk specifikation

Video input channels	8 channels
Maximum resolution	7680 x 4320 pixels
Internal memory	16 MB
Internal memory type	DDR5

Number of HDDs installed	1
HDD capacity	4 GB
Number of HDDs supported	2
Total installed storage capacity	4 GB
Maximum storage capacity	8 TB
HDD interface	SATA
HDD size	3.5 "

Ethernet LAN (RJ-45) ports	2
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	8
HDMI output	Yes
HDMI ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
DC-in jack	Yes
Networking standards	IEEE 802.3at

Brand compatibility	Ajax
Reset button	Yes
Product colour	Black
Certification	UL/cUL, BIS, CE, KC, VCCI, RCM, BSMI, FCC, NOM

Built-in processor	Yes

Power consumption (max)	270 W
Power consumption (typical)	75 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Output current	3.5 A
Total Power over Ethernet (PoE) budget	135 W

Windows operating systems supported	Yes

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Storage temperature (T-T)	-40 - 65 °C
Storage relative humidity (H-H)	10 - 90 %

Compliance certificates	Trade Agreements Act (TAA)
Safety warning	CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, RCM AS/NZS 62368. 1:2018, IS 13252

Width	330 mm
Depth	230 mm
Height	78 mm
Weight	5800 g

AC adapter included	Yes
Quick installation guide	Yes
