Produktbeskrivning

A surveillance cabinet with extended room for installation of critical system equipment. It’s designed with the integrator in mind to ensure that the product can be installed efficiently.

Versatile cabinet with extended depth
AXIS TQ1817-VE can be ordered stand-alone, but it’s also possible to buy its spare part AXIS T1816-VE Cabinet Door, to add a deeper door to AXIS T98A15-VE Surveillance Cabinet. The cabinet itself ships empty. AXIS TQ1817-VE is designed to offer room for installation of various Axis accessories and system devices. Three example setups are shown to the right:

Deployable surveillance solutions
Together with our partners, Axis provides innovative solutions when a traditional network is impractical or unavailable. We deliver high-end surveillance solutions for temporary or remote sites, without the need for a dedicated infrastructure. Whether it’s remote supervision of a distant location, or temporary provisions for a music festival or construction project, Axis and our partners provide leading-edge surveillance capabilities that are quick and easy to install. Our equipment integrates with our partners’ technology for comprehensive coverage. For example, you can use cameras housed in pre-configured cabinets with built-in 4G/LTE routers, supported by access control technology, remote video management software, perimeter protection, audio features, and much more.



Viktiga egenskaper

Axis TQ1817-VE. Type: Cabinet, Placement supported: Outdoor, Brand compatibility: Axis. Width: 282 mm, Depth: 229 mm, Height: 361 mm. Quantity per pack: 1 pc(s)



Teknisk specifikation

Type	Cabinet
Placement supported	Outdoor
Brand compatibility	Axis
Compatibility	AXIS Q1700-LE License Plate, AXIS Q1805-LE Bullet, AXIS Q1806-LE Bullet, AXIS Q1808-LE Bullet, AXIS Q1809-LE Bullet
Product colour	White
Housing material	Polycarbonate (PC)
International Protection (IP) code	IP66
IK code	IK10
Protection features	Vandal proof

Depth	229 mm
Width	282 mm
Height	361 mm
Weight	4100 g

Quantity per pack	1 pc(s)

Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	10 - 100 %
Storage temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %

Warranty period	3 year(s)
Compliance certificates	REACH,RoHS,Trade Agreements Act (TAA),UL,cUL
Doesn't contain	BFR,CFR,PVC
