Produktbeskrivning

Certified (ATEX, IECEx, EAC Ex and IA) for use in potentially combustible environments, ExCam XPT Q6075 offers HDTV 1080p and 40x optical zoom for great overview and excellent detail. Featuring Axis Lightfinder 2.0, it captures images with more realistic and saturated colors and sharper images of moving objects. It includes autotracking 2 with click and track functionality for active object tracking, and orientation aid with support for dynamic overlays for quick orientation. Enhanced security features such as signed firmware and secure boot ensure the integrity and authenticity of the firmware. Furthermore, Axis Zipstream with support for H.264/H.265 significantly lowers bandwidth and storage requirements.



Viktiga egenskaper

Axis 01928-001. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Form factor: Bullet, Housing material: Stainless steel. Tilt angle range: 0 - 180°, Tilt speed: 450 °/sec, Pan range: 0 - 360°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 40x, Digital zoom: 12x, Focal length range: 4.25 - 170 mm



Teknisk specifikation

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
PTZ control	Yes
PTZ modes	Preset point
Day/night mode	Yes
Number of languages	11
Dynamic range	120 dB
Languages support	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,POR,RUS

Form factor	Bullet
Mounting type	Wall
Housing material	Stainless steel
Protection features	Corrosion resistant
International Protection (IP) code	IP66, IP68

Tilt angle range	0 - 180 °
Tilt speed	450 °/sec
Pan range	0 - 360 °
Pan speed	450 °/sec
Camera shutter speed	1/11000 - 1/3 s

Sensor type	CMOS
Optical sensor size	1/2.8 "
Progressive scan	Yes

Number of lenses	1
Zoom capability	Yes
Optical zoom	40 x
Digital zoom	12 x
Focal length range	4.25 - 170 mm
Focus adjustment	1.6 - 5.0

Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264,H.265,M-JPEG
Supported graphics resolutions	320 x 180,1920 x 1080 (HD 1080)
Supported video modes	1080p
Video recording	Yes
Frame rate	60 fps
Video intelligence analytic	Yes
Thermal frame rate (NTSC)	50 - 60 Hz
Video streaming	Yes
Text caption overlay	Yes
Image stabilizer	Yes

Ethernet LAN	Yes
Networking standards	IEEE 802.3at
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTP/2, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, NTCIP, LLDP,

Built-in HDD	Yes
HDD capacity	1 GB
Card reader integrated	Yes
Compatible memory cards	MicroSDXC
Maximum memory card size	128 GB
Flash memory	512 MB

Password protection	Yes
IP address filtering	Yes
HTTPS encryption	Yes
Pixel counter	Yes
Security algorithms	EAP-TLS,HTTPS
Alert notification type	E-mail,Snapshot alert message

Power source type	PoE
Power consumption (typical)	11 W
Power consumption (max)	17.1 W
Power consumption (Power over Ethernet (PoE))	11 W

Operating temperature (T-T)	-50 - 50 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 100 %

Height	378 mm
Diameter	195 mm
Weight	20000 g

Number of cameras	1
