Produktbeskrivning

This DisplayPort 1.2 to Dual HDMI MST Hub allows a DisplayPort enabled device to connect to two HDMI enabled displays for video mirroring, video extension, or viewing a single video image across two displays. The hub is perfect for graphic design, spreadsheet analysis, and digital signage applications.

Improve multitasking and increase productivity by configuring the hub to work as a splitter with the same video image on each display, extending a video image to multiple displays, or expanding a video image by joining multiple monitors together as one display. The hub is ideal for a multiple display desk setup and the lightweight, small form factor, also makes it easy to carry while traveling or just on the go.

The hub supports resolutions up to 4K (3840 x 2160) at 60 Hz when connected to a single display or 4K (3840 x 2160) at 30 Hz when connected to dual displays and has a max bandwidth of 5.4 Gbps.



Egenskaper

Connector 1
(1) DisplayPort Male

Connector 2
(2) HDMI Female, (1) USB Micro-B Female

Colour
Black

Warranty
3 Years



Teknisk specifikation

Typ av enhet	Video-/ljudomkopplare - 2 portar
Modell	Skrivbordsmodell
Undertyp	HDMI / DisplayPort
Portar	2 x HDMI
Max upplösning	3840 x 2160 @ 60 Hz
Funktioner	7.1-kanaligt ljudstöd, Signal Sustain Technology (SST), Supports MultiStream (MST), stöd för dubbla skärmar
Standarder som följs	USB 2.0

Gränssnitt	2 x HDMI-utgång 1 x DisplayPort-ingång 1 x mikro-USB (enbart ström)

Färg	Svart
Standarder som följs	DisplayPort 1.2, RoHS II 2011/65/EU

Vikt	54 g

Service och support	Begränsad garanti - 3 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	50 °C
Min temperatur vid förvaring	-25 °C
Max temperatur vid förvaring	70 °C
