Produktbeskrivning

The Cisco SFP-10G-SR-I is a multirate 10GBASE-SR, 10GBASE-SW and OTU2/2e module for industrial operating temperature range. This module also supports CPRI datarate options 3, 4, 5, 6, 7, 7a, 8. It supports a link length of 26m on standard Fiber Distributed Data Interface (FDDI)-grade Multimode Fiber (MMF). Using 2000MHz*km MMF(OM3), up to 300m link lengths are possible. Using 4700MHz*km MMF (OM4), up to 400m link lengths are possible.



Viktiga egenskaper

Cisco SFP-10G-SR-I=. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Product colour: Metallic. Power consumption (typical): 1 W. Certification: MSA



Teknisk specifikation

SFP transceiver type	Fiber optic
Maximum data transfer rate	10000 Mbit/s
Interface type	SFP+
Multi-mode fiber (MMF) supported	Yes
Fiber optic connector	LC
Fiber cable diameters supported (core/cladding)	50/125 µm
SFP transceiver standard	SR
Maximum transfer distance	400 m
Wavelength	850 nm
Tx power (min)	-1.2 dBmW
Tx power (max)	-7.3 dBmW
Rx power (min)	-1 dBmW
Rx power (max)	-9.9 dBmW
Networking standards	IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3u
Duplex system	Full

Product colour	Metallic
Plug and Play	Yes
Hot-swap	Yes
Certification	MSA

Power consumption (typical)	1 W

Operating temperature (T-T)	-40 - 85 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
