Produktbeskrivning

The Cisco Aironet AIR-ANT2524V4C-RS= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved performance in mind. It provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions is required. This FCC-approved omnidirectional antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.



Viktiga egenskaper

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), 4 Ports, Ceiling Mount, 1-Year Limited Hardware Warranty (AIR-ANT2524V4C-RS=). Antenna gain level (max): 4 dBi, Frequency band: 2.4/5 GHz, Gain: 4 dBi. Antenna type: Omni-directional antenna, Antenna connector type: RP-TNC, Polarization: Linear polarization. Width: 184 mm, Depth: 25 mm, Height: 184 mm. Package width: 194.8 mm, Package depth: 215.9 mm, Package height: 98 mm. Quantity per pack: 1 pc(s)



Teknisk specifikation

Antenna gain level (max)	4 dBi
Frequency band	2.4/5 GHz
Gain	4 dBi
Antenna gain (2.4 GHz)	2 dBi
Antenna gain (5 GHz)	4 dBi

Antenna type	Omni-directional antenna
Antenna connector type	RP-TNC
Polarization	Linear polarization
Mounting	Ceiling
Country of origin	Malaysia

Operating temperature (T-T)	0 - 56 °C

Width	184 mm
Depth	25 mm
Height	184 mm
Weight	590 g
Package width	194.818 mm
Package depth	215.9 mm
Package height	98.044 mm
Package weight	770.98 g

Quantity per pack	1 pc(s)
