Produktbeskrivning
The Cisco ASR 1000 Series Fixed Ethernet Line Card is a fixed-port Ethernet line card for the Cisco ASR 1000 Series Aggregation Services Routers. The line card is capable of 40-Gbps full-duplex traffic forwarding using a fixed-port interface design. This line card has twenty 1 Gigabit Ethernet ports and two 10 Gigabit Ethernet ports.
The Small Form-Factor Pluggable (SFP) and 10-Gbps SFP (XFP) modules allow you to configure the line card for different media types and different optical requirements, as available. The line cards have one power LED, one line-card status LED, and 22 port or link-status LEDs.
The Cisco ASR 1000 Series Fixed Ethernet Line Cards have the twenty 1 Gigabit Ethernet and two 10 Gigabit Ethernet ports built in, allowing the Cisco ASR 1000 Series Routers to achieve greater Ethernet density and a lower price per port. The Ethernet line card takes the slot of the SIP with the twenty 1 Gigabit Ethernet and two 10 Gigabit Ethernet ports built in.
Egenskaper
● Carrier Ethernet, IEEE Standard 1588, SyncE (SyncE), and ITU-T Y.1731
● Low price per port
● Rich Ethernet Layer 2, Layer 3, IP, IPv6, and Multiprotocol Label Switching (MPLS) packet-processing capabilities as previously provided on Cisco ASR 1000 platforms
● Ingress and egress QoS as previously provided on Cisco ASR 1000 platforms
● Egress queuing capability as previously provided on Cisco ASR 1000 platforms
● High- and low-priority lanes to Cisco ASR 1000 Series Embedded Services Processor (ESP) for high priority, low-latency forwarding
Teknisk specifikation
Allmänt
Typ av enhet | Expansionsmodul |
Formfaktor | Insticksmodul |
Nätverk
Portar | 10Gb Ethernet x 6 |
Anslutningsteknik | Kabelansluten |
Datalänkprotokoll | 10 Gigabit Ethernet |
Expansion/Anslutning
Gränssnitt | 6 - XFP |
Kompatibilitetsinformation
Designat för | Cisco ASR 1001, 1001 VPN and Firewall Bundle, 1001 VPN Bundle, 1001-X, 1002, 1002 BB Bundle, 1002 FPI Bundle, 1002 HA Bundle, 1002 Security HA Bundle, 1002 Security VPN+FW Bundle, 1002 Special Bundle, 1002 VPN and Firewall Bundle, 1002 VPN Bundle, 1002-F, 1002-F Security HA Bundle, 1002-F VPN and Firewall Bundle, 1002-F VPN Bundle, 1002-X, 1002-X 10G HA Bundle, 1002-X Base Bundle, 1002-X HA Bundle, 1002-X Security + High Availability Bundle, 1002-X Security Bundle, 1002-X Security HA Bundle, 1002-X Special Bundle, 1002-X VPN Bundle, 1004, 1004 FPI Bundle, 1004 HA Bundle, 1004 Security HA Bundle, 1004 VPN and Firewall Bundle, 1004 VPN Bundle, 1006, 1006 BB Bundle, 1006 FPI Bundle, 1006 HA Bundle, 1006 Security HA Bundle, 1006 VPN and Firewall Bundle, 1006 VPN Bundle, 1013 |
