Produktbeskrivning

The Cisco Catalyst 9105 Series Access Points are the most versatile next generation access point in enterprise grade. They are resilient, secure, and intelligent.

An increasing numbers of devices connect to the network every year, ranging from high-performance client devices to low-bandwidth IoT devices, which puts your current network at risk for slower speeds. The Catalyst 9105 Access Points provide a seamless experience anywhere for everyone, with high scaling and unmatched performance in diverse network deployments. Going beyond the Wi-Fi 6 (802.11 ax) standard, the Catalyst 9105 Access Points provides integrated security, resiliency, and operational flexibility as well as increased network intelligence.

With the Catalyst 9105 Access Points, you can secure remote workers or the micro-office. The Catalyst 9105 access point is perfect for teleworker deployment because of its small form factor and low power consumption. This easy-to-install teleworker access point provides secure wired and wireless access for organizations with employees who work from home. The Catalyst 9105 teleworker access points are bundled with necessary accessories for easy home deployment.

The Cisco Catalyst 9105 Series Access Points, paired with the Cisco Digital Network Architecture (Cisco DNA), are enterprise-class products that will address both your current and future needs. They are the first step in updating your network to take better advantage of all of the features and benefits that Wi-Fi 6 provides.

Cisco User Defined Network, allows IT to give end users control of their very own wireless network partition on a shared network. End users can then remotely and securely deploy their devices on this network. Perfect for university dormitories or extended hospital stays, Cisco User Defined Network grants both device security and control, allowing each user to choose who can connect to their network.



Teknisk specifikation

Typ av enhet	Trådlös åtkomstpunkt
Robust design	Inomhus
Bredd	15 cm
Djup	15 cm
Höjd	3 cm
Vikt	329.5 g
Lokalisering	Indien

Formfaktor	Extern
Anslutningsteknik	Trådlös
Linjekodningsformat	OFDMA
Datalänkprotokoll	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6)
Metod för spridningsspektrum	OFDMA
Frekvensband	2.4 GHz, 5 GHz
Statusindikatorer	Status
Funktioner	Stöd för DFS, Maximum Ratio Combining (MRC), 802.1x-autentisering, cyklisk växlingsmångfald (CSD), stråleformingsteknologi, paketaggregering A-MPDU, paketaggregering A-MSDU, 2x2 MU-MIMO-teknologi, säker omstart, målväntetid (TWT), bildsignering, Cisco Trust-förankringsmodul, BSS-färgning
Krypteringsalgoritm	AES, TLS, PEAP, TTLS, WPA2, EAP-SIM, WPA3, EAP-FAST, EAP-TLS, EAP-TTLS
Verifieringsmetod	MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM
Standarder som följs	IEEE 802.3, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6

Antenn	Inbyggd
Antal antenner	2
Riktning	Rundstrålande

Kompatibel med Internet of Things (IoT)	Ja
Kommunikationsteknologi	Bluetooth Low Energy (LE)

Gränssnitt	1 x 1000Base-T - RJ-45 1 x administration - RJ-45

Standarder som följs

CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 4268, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, EN 62209-1, SRRC, EN 50385, EN 62209-2, LP0002, RSS-247, KN32, KN35, AS/NZS CISPR 32 Class B, EN 62368-1, IEC 62368-1, CISPR 32, EN 55032, EN 61000-6-1:2007, CAN/CSA-C22.2 No. 60950-1, EN 300 328 V2.1.1, ICES-003:2016 issue 6 Class B, EN 301 489-1 V2.1.1, VCCI-CISPR 32:2016, CNS, AS/NZS 2772, EN 301 489-17 V3.1.1, ARPANSA, EN 55035:2017, KN 61000-3-2, KN 61000-3-3, KN 489-1, QCVN, KN 489-17, RSP-100, RSS-GEN, EN 301 893 V2.1.1, QCVN 118:2018, 47 CFR Part 1.1310, 47 CFR Part 2.1091, QCVN 112:2017, Japan Std. 33a, Japan Std. 66, Japan Std. 71

Stöd för PoE (Power Over Ethernet)	PoE

Medföljande programvara	Cisco-inbäddad trådlös mjukvarubild

Service och support	Begränsad garanti - förtida byte av hårdvara - livstid - svarstid: 10 dagar

Min temperatur vid drift	0 °C
Max temperatur vid drift	50 °C
Luftfuktighet vid drift	10 - 90 % (icke-kondenserade)
