Produktbeskrivning

Hyperconnectivity with steady performance, exponential growth of Internet of Things (IoT) devices, and next-generation cloud-scale applications - these trends are causing enterprises to look beyond traditional connectivity to cellular solutions, especially high-speed 5G and 4G technologies, to connect hard-to-reach areas and to securely support global operations. Powered by gigabit-class 5G and 4G standards, the Cisco Catalyst Cellular Gateways bring blazing-fast cellular connection to virtually any Cisco host platform. Connected to the host router via Ethernet and available with Power over Ethernet (PoE), the cellular gateways can be placed wherever cellular reception is strongest, making installation much easier and more reliable than traditional coaxial cable antenna extensions. The ability to support new applications, either cloud hosted or on-premises, and to connect more devices reliably and flexibly, can make it easier to migrate to a wireless WAN with guaranteed Quality of Service (QoS). The cellular gateways' faster 5G and 4G speeds mean that wireless could be considered for primary connectivity, alongside internet and Multiprotocol Label Switching (MPLS) modes of transport. Cisco Catalyst Cellular Gateways connect your users and devices to trusted cloud and enterprise applications using 5G and 4G LTE Advanced Pro technologies. When combined with Cisco SD-WAN, they enable you to automate deployment, manage policies, and monitor network traffic over a cellular WAN with greater flexibility.



Egenskaper

● Multigigabit 5G or 4G connectivity allows the gateways to be used for primary or failover high-speed cellular WAN
● Can be deployed in many different environments where space, heat dissipation, and low power consumption are critical factors
● Connect to virtually any Cisco host router via Ethernet
● Deploy up to 100 m from host router via Ethernet
● Multiple mounting options
● PoE and AC power options
● Support for external antenna
● Seamless extension of business policy from the branch to the cloud
● Zero-touch provisioning
● IP pass-through mode using a single Packet Data Network (PDN) for operational simplicity
● Console port for out-of-band management
● Upgrade cellular capability without a full router refresh
● Ability to upgrade host router and continue to use the same cellular gateway



Teknisk specifikation

Typ av enhet	Router
Modell	Skrivbordsmodell
Anslutningsteknik	Kabelansluten
Datalänkprotokoll	10 Gigabit Ethernet, 2.5 Gigabit Ethernet
Nätverksprotokoll	MPLS
Protokoll för administration på distans	HTTP, CLI
Funktioner	Quality of Service (QoS), WWAN-support, Zero-touch provisioning (ZTP), support för SD-WAN, 4x4 MIMO-teknik, Secure Unique Device Identification (SUDI)
Standarder som följs	EN 61000-3-2, IEC 61000-3-2, EN55024, EN 61000-6-1, AS/NZS 60950-1, ICES-003 klass A, UL 60950-1, IEC 60950-1, EN 60950-1, FDA, EN 301 489-1, FCC CFR47 Part 15 B Class A, EN 300 386, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, EN 55032, CISPR 32 Class A, EN 301 489-19, CAN/CSA-C22.2 No. 60950-1, VCCI-CISPR 32:2016 Class A, EN 55035, IEC/EN 61000-3-3, IEC/EN 60825, ETSI EN 301 489-52
RAM	1 GB
Flash-minne	4 GB
Statusindikatorer	Status

Typ	Trådlöst mobilmodem
Mobilband	LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B5, LTE B39, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B46, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48, LTE B71, 5G n78, 5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n20, 5G n25, 5G n28, 5G n40, 5G n41, 5G n66, 5G n71, 5G n77, 5G n79, LTE B34, 5G n38, WCDMA B1, WCDMA B19, WCDMA B9
Max överföringshastighet	2.44 Gbps

Kompatibel med Internet of Things (IoT)	Ja

Gränssnitt	1 x 2.5G/10 Gigabit Ethernet - RJ-45 Konsol: 1 x RJ-45 AUX: 1 x RJ-45
Expansionskortplatser	2 (totalt)/ 2 (ledig) x Micro-SIM

Antenn	Extern löstagbar
Antal antenner	4

Energiförbrukning vid drift	21 Watt

MTBF (genomsnittstid mellan fel)	1,048,340 timmar

Bredd	25.1 cm
Djup	25.1 cm
Höjd	21.1 cm

Service och support	Begränsad garanti - 1 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	45 °C
Luftfuktighet vid drift	10 - 85 % (icke-kondenserande)
