Produktbeskrivning

Cisco Catalyst 8300 Series Edge Platforms (Catalyst 8300) with Cisco IOS XE SD-WAN Software deliver Cisco’s secure, cloud-scale SD-WAN solution for the branch. The Catalyst 8300 Series is purpose-built for high performance and integrated SD-WAN Services along with flexibility to deliver security and networking services together from the cloud or on premises. It provides higher WAN port density and a redundant power supply capability. The Catalyst 8300 Series Edge Platforms have a wide variety of interface options to choose from—ranging from lower and higher module density with backward compatibility to a variety of existing WAN, LAN, voice, and compute modules. Powered by Cisco IOS XE, fully programmable software architecture, and API support, these platforms can facilitate automation at scale to achieve zero-touch IT capability while migrating workloads to the cloud. Catalyst 8300 Series Edge Platforms also come with Trustworthy Solutions 2.0 infrastructure that secures the platforms against threats and vulnerabilities with integrity verification and remediation of threats.

The Catalyst 8300 Series Edge Platforms are well suited for medium-sized and large enterprise branch offices for high WAN IPSec performance with integrated SD-WAN services.



Viktiga egenskaper

Cisco C8300-1N1S-6T. Networking standards: IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah, Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 100,1000 Mbit/s. USB version: 3.2 Gen 1 (3.1 Gen 1). Switching protocols: MPLS, Routing protocols: BGP, EIGRP, HSRP, IP, IS-IS, LISP, MPLS, OSPF, OSPFv3, RIP, RIP-2, VRRP, IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL). Security algorithms: 3DES, 128-bit AES, 256-bit AES, 256-bit AES-XTS, 2048-bit RSA, DES, MD5, SHA-1, SHA-2, SHA-256,..., Authentication method: AAA, RSA (2048 bit), ESP-256-CBC, HMAC-SHA1, ECDSA (256/384 bit). Processor manufacturer: Intel, Storage media: SSD, Internal storage capacity: 16 GB



Teknisk specifikation

Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	No
SFP WAN	Yes

Networking standards	IEEE 802.1Q,IEEE 802.1ag,IEEE 802.3ah
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	100,1000 Mbit/s

Web-based management	Yes
Quality of Service (QoS) support	Yes

Ethernet LAN (RJ-45) ports	4
SFP+ module slots quantity	2
USB ports quantity	2
USB version	3.2 Gen 1 (3.1 Gen 1)

DHCP client	Yes
DHCP server	Yes
Switching protocols	MPLS
Routing protocols	BGP,EIGRP,HSRP,IP,IS-IS,LISP,MPLS,OSPF,OSPFv3,RIP,RIP-2,VRRP
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Security algorithms	3DES,128-bit AES,256-bit AES,256-bit AES-XTS,2048-bit RSA,DES,MD5,SHA-1,SHA-2,SHA-256,SHA-384,SHA-512
Firewall	Yes
Authentication method	AAA, RSA (2048 bit), ESP-256-CBC, HMAC-SHA1, ECDSA (256/384 bit)
URL filtering	Yes
Access Control List (ACL)	Yes
Network address translation (NAT)	Yes

Processor manufacturer	Intel
Storage media	SSD
Internal storage capacity	16 GB
Flash memory	8192 MB
Internal memory	8192 MB
Internal memory type	DDR4
Maximum memory card size	32 GB
Mean time between failures (MTBF)	536060 h

Product colour	Grey
Rack mounting	Yes
Rack capacity	1U
LED indicators	Yes

Power source type	AC
AC input voltage	85 - 264 V

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 85 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3050 m

Width	444.5 mm
Depth	412.75 mm
Height	43.9 mm
