Produktbeskrivning

The Cisco Secure Firewall with the Firepower 1010 appliance and ASA software provides robust, proven Layer 3 and 4 security control. It includes Power-over-Ethernet and switchport capability for maximum flexibility, support for advanced remote access VPN termination, and BGP and OSPF routing functions. When Layer 7 application control and advanced threat defence are also required, select instead the Firepower 1010 appliance with FTD software.



Viktiga egenskaper

Cisco Secure Firewall: Firepower 1010 Security Appliance with ASA Software, 8 Gigabit Ethernet (GbE) Ports, Up to 2 Gbps Throughput, 90-Day Limited Warranty (FPR1010-ASA-K9). Firewall throughput: 2 Gbit/s, IPSec VPN throughput: 0.5 Gbit/s. Internal memory: 8096 MB, Internal memory type: DDR4, Processor family: Intel. Connectivity technology: Wired, Console port: RJ-45, Remote management port: RJ-45 (Gigabit). Storage media type: SSD, Storage drive interface: Serial ATA, Total storage capacity: 200 GB. Form factor: 1U



Teknisk specifikation

Firewall throughput	2 Gbit/s
IPSec VPN throughput	0.5 Gbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	25000

Built-in processor	Yes
Processor family	Intel
Processor cores	4
Reset button	Yes

Connectivity technology	Wired
Gigabit Ethernet (copper) ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Console port	RJ-45
Number of console ports	1
Remote management port	RJ-45 (Gigabit)

Internal memory	8096 MB
Internal memory type	DDR4

Storage media type	SSD
Storage drive interface	Serial ATA
SSD capacity	200 GB
Total storage capacity	200 GB

Rack mounting	Yes
Form factor	1U

Power supply	30 W

Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Country of origin	Mexico

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Storage relative humidity (H-H)	10 - 90 %
Non-operating altitude	0 - 4570 m
Operating altitude	0 - 3000 m

Width	194.4 mm
Depth	205 mm
Height	46.2 mm
Weight	1360 g

Package width	698.5 mm
Package height	317.5 mm
Package depth	812.8 mm
Package weight	2947.85 g

Firewall throughput	2000 Mbit/s
