Produktbeskrivning

The Firewall Management Center series runs software that provides extensive intelligence about the users, applications, devices, threats, and vulnerabilities that exist in your network. It also uses this information to analyze your network’s vulnerabilities. It then provides tailored recommendations on what security policies to put in place and what security events you should investigate.



Viktiga egenskaper

Cisco FMC4700. Heat dissipation: 2626 BTU/h. Connectivity technology: Wired, Console port: RJ-45, Remote management port: RJ-45 (Gigabit)/SFP+. Storage media type: HDD, HDD capacity: 1.2 TB, Total storage capacity: 12 TB. Form factor: 1U, Number of fans: 8 fan(s). AC input voltage: 90-264 V, AC input frequency: 47/63 Hz, Input current: 9.2 A



Teknisk specifikation

Heat dissipation	2626 BTU/h

LED indicators	Yes

Connectivity technology	Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	2
Console port	RJ-45
Number of console ports	1
Remote management port	RJ-45 (Gigabit)/SFP+
VGA (D-Sub) ports quantity	1
SFP+ module slots quantity	2
Remote management ports quantity	2

Storage media type	HDD
RAID support	Yes
HDD capacity	1200 GB
Total storage capacity	12000 GB
Number of HDDs installed	10
RAID levels	6

Rack mounting	Yes
Form factor	1U
Built-in fan	Yes
Number of fans	8 fan(s)

AC input voltage	90-264 V
AC input frequency	47/63 Hz
Input current	9.2 A

Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	8 - 90 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12192 m

Width	43 mm
Depth	762 mm
Height	429 mm
Weight	17000 g
