Product overview

The Cisco Wireless 9172 Series Wi-Fi 7 access points are high-performance wireless solutions designed for environments like boutique hotels, healthcare clinics, retail stores, student housing, and distributed business locations such as regional branches and logistics hubs. With tri-radio functionality across 2.4-GHz, 5-GHz, and 6-GHz bands, the 9172 Series provides reliable, high-speed connectivity (frame rate up to 9000 Mbps) for spaces with low to moderate device density. Flexible deployment options—cloud, on-premises, or hybrid—allow seamless integration into existing networks.

These access points are designed to enhance wireless performance and enable smarter spaces. The 9172H model is tailored for hospitality and multi-dwelling environments, offering additional LAN ports for wired devices and Bluetooth Low Energy (BLE) IoT capabilities for smart room automation. The 9172I model supports flexible configurations, including a high-density 4x4 radio option for 5 GHz when the 6-GHz band is disabled, making it ideal for retail, healthcare, and branch office use. Both models feature plug-and-play setup with mount compatibility for quick and efficient deployment.

For customers, the 9172 Series delivers reliable Wi-Fi 7 performance, enabling advanced applications like IoT integration, telehealth, and seamless customer experiences. The primary business benefit is future-ready connectivity with energy efficiency, reducing power consumption while supporting evolving network demands. This makes the 9172 Series a cornerstone for modernizing and optimizing network infrastructure.



Viktiga egenskaper

Cisco CW9172i. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 9000 Mbit/s. Security algorithms: EAP, WPA2, WPA3. Ethernet LAN data rates: 100,1000,2500,5000 Mbit/s. Power over Ethernet (PoE). Product colour: White



Teknisk specifikation

2.4 GHz	Yes
6 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	9000 Mbit/s
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Networking standards	IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11be,IEEE 802.11n
Bluetooth	Yes
Bluetooth Low Energy (BLE)	Yes
Bluetooth version	5.3
MIMO	Yes
MIMO type	Multi User MIMO
Spread spectrum method	OFDMA
Band steering	Yes
BeamForming	Yes
Receiver sensitivity	2.4 GHz, 5 GHz, 6 GHz or 2.4 GHz + 5 GHz (4x4:4)

Security algorithms	EAP,WPA2,WPA3

Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	1

Power over Ethernet (PoE)	Yes
Power consumption (typical)	30 W

Placement	Ceiling,Wall
Product colour	White

Antenna type	Internal
Antenna direction type	Omni-directional
Antenna gain level (max)	6 dBi

Flash memory	16000 MB
Internal memory	4096 MB

Width	200 mm
Depth	200 mm
Height	53 mm
Weight	874 g

Quick start guide	Yes

Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C

Quantity per pack	1 pc(s)
