High-Performance Wi-Fi 7 Wireless

Cisco Wireless 9176 Series Wi-Fi 7 access points are ideal for high-density environments and critical applications. These access points also allow choosing between on-premises and cloud management. Cisco Wireless' Wi-Fi 7 access points can leverage Wi-Fi 7 to support video streaming, augmented reality (AR), and virtual reality (VR) applications. These access points offer real-time insights and personalized user experiences.

The Cisco Wireless 9176 Series Wi-Fi 7 access points enable operation in the 2.4, 5 and 6GHz bands for higher throughput and capacity. These access points provide three 4x4 radios and IoT radios.

The Cisco Wireless 9176 Series offers an Omni-directional antenna model, the CW9176I, suitable for most enterprise deployments and an internal directional antenna model, the CW9176D1, designed for use cases and areas with high ceilings such as auditoriums, warehouses, and other large open space areas. The CW9176D1 should be leveraged where typically external antennas would be required. Since the CW9176D1 uses a built-in directional antenna, it eliminates the need for additional hardware to achieve ideal wireless coverage.

Operational management is flexible because the network management can be changed anytime. If a network with Cisco Wireless 9176 Series access points was originally an on-premises deployment, it can be changed to cloud-based management without the need to purchase and redistribute additional hardware.

Cisco Meraki Cloud Management
Pairing the Cisco Wireless 9176 Series access points with the Meraki cloud platform provides a unified IT experience for network monitoring and management. The Meraki dashboard has an intuitive and interactive web interface.

Through the dashboard, Meraki provides sophisticated and scalable tools to automate network optimization, deploy policy and segmentation configurations across thousands of sites and devices. It also can manage a full-stack network with SD-WAN, Access, and IoT technologies. The platform supports over 3.5 million active networks around the world.

Working together, the Cisco Wireless 9176 Series and Cisco Meraki offer such features as:

- Cisco Spaces
- Cisco Identity Services Engine
- Meraki Health intelligent optimization and assurance
- Meraki Vision, smart cameras, and sensors for network closet monitoring

Cisco Catalyst Center and Catalyst 9800 WLC support
Cisco Wireless 9176 Series access points can also be managed with Catalyst 9800 WLC and Cisco Catalyst Center. Cisco Catalyst Center allows you to understand your network with real-time analytics, quickly detect and contain security threats, and easily provide network-wide consistency through automation and virtualization.

Working together, the Cisco Wireless 9176 Series and Catalyst Center offer such features as:

- Cisco Spaces
- Cisco Identity Services Engine
- Cisco Catalyst Center Analytics and Assurance along with Intelligence Capture (iCAP)



Viktiga egenskaper

Cisco 9176 Series CW9176I-RTG. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 18000 Mbit/s. Security algorithms: WPA-PSK, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal. Ethernet LAN data rates: 100,1000,2500,5000,10000 Mbit/s. Power over Ethernet (PoE). Product colour: White



Teknisk specifikation

2.4 GHz	Yes
6 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	18000 Mbit/s
Ethernet LAN data rates	100,1000,2500,5000,10000 Mbit/s
Networking standards	IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11be,IEEE 802.11n
Bluetooth	Yes
Bluetooth Low Energy (BLE)	Yes
Bluetooth version	5.3
MIMO	Yes
MIMO type	Multi User MIMO
Spread spectrum method	OFDMA
Band steering	Yes
BeamForming	Yes

Security algorithms	WPA-PSK,WPA2-Enterprise,WPA2-Personal,WPA3-Enterprise,WPA3-Personal

Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1

Power over Ethernet (PoE)	Yes
Power consumption (typical)	9 W

Placement	Ceiling,Wall
Product colour	White
LED indicators	Yes

Antenna type	Internal
Antenna direction type	Omni-directional
Antennas quantity	4
Antenna gain level (max)	6 dBi

Width	242.3 mm
Depth	242.25 mm
Height	52.8 mm
Weight	1560 g

Quick start guide	Yes

Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C

Quantity per pack	1 pc(s)
